9. Disassembly Diagrams And Parts Lists

9.1 Mainframe (1-Pen Type)
No. Part No.
E1 772232120
E2 772232100
E3 773503490
E4 122927320
692807300
E5 122907030
1 022900072
2 022900081
022900201
022900130
022900140
3 022907302
4 022900051
5 022907391
6 022907291
7 022907231
8 022900740
022900750
9 022907410
10 022900041
12 792201150
12 792291702
13 022900013
022900103
14 022900062
16 022907253
17 022900031
18 022903751
022903721
19 022903721
022903781
FC2230-UM251-01-1600
Description
X Joint Board
X Flex. Board
High Voltage Board
Y Cable
X Cable
Corner Cover (Rear Right)
Electrostatic Panel 12
Electrostatic Panel
Magnetic Sheet 90
Magnetic Sheet EX
Power Board Cover
Corner Cover (Front Right)
Support Bracket
Support Bracket
Frame Holder Plate
Tray 12
Tray
Main Frame
Corner Cover (Front Left)
1 Pen Type Block Assembly
1 Pen T Type Block Assembly
Writing Panel 12
Writing Panel
Corner Cover (Rear Left)
Board Cover
Side Cover
Flexible Guide 12, Right
Flexible Guide, Right
Flexible Guide 12, Left
Flexible Guide, Left
Q'ty Remarks
1 PR223203 Assembly
1 PR223224 Assembly
1 PR31001C Assembly
1 CA2292-32 (-60/-90)
CA2232-32 (-EX)
1 CA2290-03
1
1 FC2200-90/ES
FC2200-90EX/ES
FC2200-90MG
FC2200-90EX/MG
1
1
4 M4-18
8 M4-12
2
1 FC2200-90
FC2200-90EX
2
1
1 Standard cutting pressure
1 High cutting pressure
1 FC2200-90
FC2200-90EX
1
2
2
1 FC2200-90
FC2200-90EX
1 FC2200-90
FC2200-90EX
