10.2 Key Joint Board (PR223281)

Circuit No. Part No. Description
PCB 682807810 PCB
D1, 2 503000021 Diode
R2 501303749 Resistor
R4 501303744 Resistor
R1, 3 501303765 Resistor
C1 500000651 Capacitor, ceramic
FL1, 2, 3, 4, 5, 6, 7 502010002 Filter
P101 513101177 Connector
P11 513000188 Connector
P13 513400296 Connector
P12 505200100 Connector
FC2230-UM251-01-1600
Rating Q'ty
PR223281 1
1SS254T-77 2
RNM1/4S-8.2KF 1
RNM1/4S-200ΩF 1
RNM1/4S-430ΩF 2
CC, RPE132F224Z50 1
DSS306-55FZ103N1 7
FRC5-C34L53T-OL 1
5597-16APB 1
IL-S-4P-S2T2-EF 1
IL-S-10P-S2T2-EF 1
