7.16.4 Belt running Test

Perform this test when you replace a belt.
(5) PAUSE : Press the PAUSE key to select PAUSE mode.
↓
NEXT : Press the NEXT key.
↓
NEXT : Press the NEXT key again.
↓
NEXT : Press the NEXT key again.
↓
４ : Press the ４ key to select OPTION2.
↓
４ : Press the ４ key to select TEST.
The prompt message below appears.
＜ＣＯＮＤＩＴＩＯＮ
(6) Press the １ key and then the ENTER key. The prompt message below appears.
＜ＭＥＣＨＡ
＜ＡＧＩＮＧ
(7) Press the ４ key to select BELT and to start the belt running test. When you have finished
the running test, turn off the plotter to stop the test.
FC2230-UM251-01-1600
ＳＥＬＦ ＴＥＳＴ＞
ＤＵＭＰ＞
ＩＳＯ ＰＡＴＴＥＲＮ＞
ＢＥＬＴ＞
7-25
