GRAPHTEC Cutting PRO FC2230 Series Service Manual page 8

5. DISASSEMBLY AND ADJUSTMENT
5.1 Adjusting the X-Axis Driver
5.1.1 Removing the X Motor Cover
5.1.2 Adjusting the X Drive Belt Tension
5.1.3 Adjusting the Belt Tension of the Front X Slider
5.1.4 Adjusting the Belt Tension of the Rear X Slider
5.1.5 Checking the Belt Tension of the Front and Rear X Slider
5.2 Adjusting the Y-Axis Driver
5.2.1 Removing the Y Motor Cover
5.2.2 Removing the Y Motor
5.2.3 Adjusting the Y Drive Belt Tension
5.3 Adjusting the Y Slider
5.3.1 Removing the Y Bar
5.3.2 Adjusting the Y Slider Belt Tension
5.4 Adjusting the Roller Pressure of the Front X Slider
5.5 Adjusting the Roller Pressure of the Rear X Slider
5.6 Adjusting the Roller Pressure of the Y Slider
5.7 Adjusting the Position of Sensor Dog Y
5.8 Mounting the Y Slider on the Y Flexible Printed Circuit Cable
5.9 Pen Block(One-Pen Specifications)
5.9.1 Removing the Pen Block Cover
5.9.2 Removing the Pen Block
5.9.3 Adjusting the Pen Block
5.10 Pen Block(Two-Pen Specifications)
5.10.1 Removing the Pen Block Cover
5.10.2 Removing the Pen Block
5.10.3 Adjusting the Pen Block
5.11 Using the Mechanical Adjustment Jigs
5.12 Replacing the Y Bar
5.12.1 Preparations
5.12.2 Replaceing the Y Bar
5.12.3 Checking the Sliding of the Y Bar Frame (Manual Check)
5.13 Adjusting the Perpendicularity Precision
5.13.1 Checking the Deviation in the Perpendicularity
5.14 Replacing the Electrostatic Adhesion Plate
5.14.1 Peeling Off the Electrostatic Adhesion Plate
5.14.2 Preliminary Preparations for Pasting On New Plate
5.14.3 Attaching the Electrostatic Adhesion Plate
