10.4 X Joint Board (PR223203)
Circuit No.
Part No.
PCB
682807030 PCB
FL1
502010002 Filter
FL2, 3
518110088 Filter
P301
513101066 Connector
P31
513000001 Connector
P303
505100040 Connector
P302
502312171 Connector
FC2230-UM-251-01-1600
Description
PR223203
DSS306-55FZ103N1
FBR07HA850NB-00
CN, 5566-02A
FRC5-C14L53T-OL
IL-G-4P-S3T2-E
IL-G-3P-S3T2-E
Rating
Q'ty
1 0-7
1
1
2
1
1
1
1
