GRAPHTEC Cutting PRO FC2230 Series Service Manual page 130

9.7 Y Drive Section (1-Pen Type)
No. Part No.
(Pen Block Unit)
60 022902401 MC Block
61 090113200 Long Magnetic Circuit Board A
62 010014101 Slide Shaft Assembly
63 021500621 50 Slide Arm
64 022906323 Hall IC Bracket
65 053203390 Guide Shaft
66 310069220 Bearing
67 053203350 MC Up Spring
68 340804012 O Ring,S4
69 034004591 Offset Pin
70 021500630 Cutter Holder
71 302200029 Pen Mounting Screw M4×L15
73 022902421 Pen Cover
74 022902412 Block Plate
80 792201150 1 Pen Type Block Assembly
81 792291702 1 Pen T Type Block Assembly
E1 772232110
E2 509410107
E3 772231350
E4 305320007
E5 110006060
E6 792150709
E7 772230310
E8 772232130
E9 162291100
E10 122907040
FC2230-UM251-01-1600
Description
X-Y Joint Board
Y Motor
1 Pen Board
Moving Coil
Flexible Printed Circuit
Height Sensor
Y Limit Switch Assembly
Pen Flex. Board
Y Flexible Cable
Cable
Q'ty Remarks
Standard Pressure Type
1 22AL
1 A0000
1
1
1
1
2 BB692ZZMC39S2S
1
1
1
1
1
1
1
Standard Cutting Pressure
1
1 High Cutting Pressure
1 PR223225 Assembly
1 UGFMED A5TGR33 Y
1 PR223107 Assembly
1 PL-326B
1 FPC10002
1
1 PR223208 Assembly
1 PR223226 Assembly
1 FCASS91010
1 CA2290-04
(2/2)
9-15
