Appendix

6.1

Composition of a process image in the Bus Coupler

An example shows the assignment of input and output channels to the process image. The sample
construction should consist of the following bus - terminal - assemblies:
Position
POS01
POS02
POS03
POS04
POS05
POS06
POS07
POS08
POS09
POS10
POS11
POS12
POS13
POS14
POS15
POS16
POS17
POS18
POS19
POS20
POS21
By default, DeviceNet only supports signal channels that are 16 bits wide. The STATUS/CONTROL BYTE is
not available. This means, for example, that an analog input terminal with 2 channels appears in the process
image with 2 x 16 bits. The images have corresponding differences with respect to byte addresses and
assignments.
Area for byte-oriented data, analog outputs
Relative byte address
0, 1
2, 3
4, 5
6, 7
8, 9
10, 11
BK52x0 and LC5200
Functional groups on the rail
Bus Coupler
Digital inputs, 2 channels
Digital inputs, 2 channels
Digital inputs, 2 channels
Digital inputs, 2 channels
Digital inputs, 2 channels
Digital outputs, 2 channels
Digital outputs, 2 channels
Digital outputs, 2 channels
Analog inputs, 2 channels
Analog outputs, 2 channels
Analog outputs, 2 channels
Analog inputs, 2 channels
Power feed terminal
Digital inputs, 2 channels
Digital inputs, 2 channels
Digital inputs, 2 channels
Digital outputs, 2 channels
Digital outputs, 2 channels
Analog outputs, 2 channels
End terminal
Bit position Process image in the controller
none O0, O1
none O2, O3
none O4, O5
none O6, O7
none O8, O9
none O10, O11
Version: 2.0.0
Appendix
Position in the block
POS11
POS11
POS12
POS12
POS20
POS20
