Mounting and wiring

4.1

Instructions for ESD protection

Destruction of the devices by electrostatic discharge possible!
The devices contain components at risk from electrostatic discharge caused by improper handling.
• Please ensure you are electrostatically discharged and avoid touching the contacts of the device directly.
• Avoid contact with highly insulating materials (synthetic fibers, plastic film etc.).
• Surroundings (working place, packaging and personnel) should by grounded probably, when handling
with the devices.
• Each assembly must be terminated at the right hand end with a KL9010 bus end terminal, to ensure the
protection class and ESD protection.
Fig. 9: Spring contacts of the Beckhoff I/O components
4.2

Dimensions

The system of the Beckhoff Bus Terminals is characterized by low physical volume and high modularity.
When planning a project it must be assumed that at least one Bus Coupler and a number of Bus Terminals
will be used. The dimensions of the Bus Couplers are independent of the fieldbus system.
BK52x0 and LC5200
NOTE
Version: 2.0.0
Mounting and wiring
19
