Documentation | EN
EK1110, EK1110-0008
EtherCAT Extension
2023-03-14 | Version: 2.6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EK1110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Beckhoff EK1110

Summary of Contents for Beckhoff EK1110

  • Page 1 Documentation | EN EK1110, EK1110-0008 EtherCAT Extension 2023-03-14 | Version: 2.6...

  • Page 3: Table Of Contents

    Nut torque for connectors........................  44 4.10 Positioning of passive Terminals.....................  45 4.11 Disposal ............................ 46 5 Commissioning ............................ 47 EK1110 - Configuration by means of the TwinCAT System Manager .......... 47 6 Error handling and diagnostics ...................... 49 Diagnostic LED .......................... 49 7 Appendix .............................. 50 EK1110, EK1110-0008 Version: 2.6...
  • Page 4 Device description ESI file/XML .................. 53 7.3.2 Firmware explanation.......................  56 7.3.3 Updating controller firmware *.efw ...................  56 7.3.4 FPGA firmware *.rbf ...................... 58 7.3.5 Simultaneous updating of several EtherCAT devices ............ 62 Support and Service........................ 63 Version: 2.6 EK1110, EK1110-0008...

  • Page 5: Foreword

    , XTS and XPlanar are registered trademarks of and licensed by Beckhoff Automation GmbH. Other designations used in this publication may be trademarks whose use by third parties for their own purposes could violate the rights of the owners. Patent Pending...

  • Page 6: Safety Instructions

    All the components are supplied in particular hardware and software configurations appropriate for the application. Modifications to hardware or software configurations other than those described in the documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG. Personnel qualification This description is only intended for trained specialists in control, automation and drive engineering who are familiar with the applicable national standards.

  • Page 7: Documentation Issue Status

    • Update structure • Technical data added • Update structure • Technical data added • Update structure • Addenda of EK1110-0008 • Migration • Technical data added • Addenda chapter "Installation instructions for enhanced mechanical load capacity" • Technical data added •...

  • Page 8: Version Identification Of Ethercat Devices

    Associated and synonymous with each revision there is usually a description (ESI, EtherCAT Slave Information) in the form of an XML file, which is available for download from the Beckhoff web site. From 2014/01 the revision is shown on the outside of the IP20 terminals, see Fig. “EL5021 EL terminal, standard IP20 IO device with batch number and revision ID (since 2014/01)”.

  • Page 9: Version Identification Of Ek Couplers

    Version identification of EK Couplers The serial number/ data code for Beckhoff IO devices is usually the 8-digit number printed on the device or on a sticker. The serial number indicates the configuration in delivery state and therefore refers to a whole production batch, without distinguishing the individual modules of a batch.

  • Page 10: Beckhoff Identification Code (Bic)

    1.4.3 Beckhoff Identification Code (BIC) The Beckhoff Identification Code (BIC) is increasingly being applied to Beckhoff products to uniquely identify the product. The BIC is represented as a Data Matrix Code (DMC, code scheme ECC200), the content is based on the ANSI standard MH10.8.2-2016.
  • Page 11 Fig. 3: Example DMC 1P072222SBTNk4p562d71KEL1809 Q1 51S678294 An important component of the BIC is the Beckhoff Traceability Number (BTN, position 2). The BTN is a unique serial number consisting of eight characters that will replace all other serial number systems at Beckhoff in the long term (e.g.

  • Page 12: Electronic Access To The Bic (Ebic)

    Electronic access to the BIC (eBIC) Electronic BIC (eBIC) The Beckhoff Identification Code (BIC) is applied to the outside of Beckhoff products in a visible place. If possible, it should also be electronically readable. Decisive for the electronic readout is the interface via which the product can be electronically addressed.
  • Page 13 EtherCAT, the eBIC of the top-level device is located in the CoE object directory 0x10E2:01 and the eBICs of the sub-devices follow in 0x10E2:nn. Profibus/Profinet/DeviceNet… Devices Currently, no electronic storage and readout is planned for these devices. EK1110, EK1110-0008 Version: 2.6...

  • Page 14: Product Description

    Ethernet cable with RJ 45 or rather M8 connector, thereby extending the EtherCAT strand electrically isolated by up to 100 m. In the EK1110 (EK1110-0008) terminal, the E-bus signals are converted on the fly to 100BASE-TX Ethernet signal representation. Power supply of both terminals to the electronics is via the E-bus.

  • Page 15: Technical Data

    EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4 Protection class IP20 Installation position variable Approval / Marking CE, EAC, UKCA, ATEX [} 29] cULus [} 31] *) Real applicable approvals/markings see type plate on the side (product marking). EK1110, EK1110-0008 Version: 2.6...

  • Page 16: Start

    Product description Start For commissioning: • mount the EK1110 as described in the chapter Mounting and wiring [} 27] • configure the EK1110 in TwinCAT as described in chapter Parameterization and commissioning [} 47]. Version: 2.6 EK1110, EK1110-0008...

  • Page 17: Basics Communication

    Protocol structure: The process image allocation is freely configurable. Data are copied directly in the I/O terminal to the desired location within the process image: no additional mapping is required. The available logical address space is with very large (4 GB). EK1110, EK1110-0008 Version: 2.6...
  • Page 18 IEEE 1588 standard. In contrast to fully synchronous communication, where synchronization quality suffers immediately in the event of a communication fault, distributed aligned clocks have a high degree of tolerance vis-à-vis possible fault-related delays within the communication system. Version: 2.6 EK1110, EK1110-0008...
  • Page 19 In addition to the new Bus Terminals with E-Bus connection (ELxxxx), all Bus Terminals from the familiar standard range with K-bus connection (KLxxxx) can be connected via the BK1120 or BK1250 Bus Coupler. This ensures compatibility and continuity with the existing Beckhoff Bus Terminal systems. Existing investments are protected.

  • Page 20: Ethercat Basics

    Basics communication EtherCAT basics Please refer to the EtherCAT System Documentation for the EtherCAT fieldbus basics. Version: 2.6 EK1110, EK1110-0008...

  • Page 21: Ethercat Cabling - Wire-Bound

    - RJ45 connector, field assembly ZS1090-0005 - EtherCAT cable, field assembly ZB9010, ZB9020 Suitable cables for the connection of EtherCAT devices can be found on the Beckhoff website! E-Bus supply A bus coupler can supply the EL terminals added to it with the E-bus system voltage of 5 V; a coupler is thereby loadable up to 2 A as a rule (see details in respective device documentation).
  • Page 22 Basics communication NOTE Malfunction possible! The same ground potential must be used for the E-Bus supply of all EtherCAT terminals in a terminal block! Version: 2.6 EK1110, EK1110-0008...

  • Page 23: Ethercat State Machine

    Before it acknowledges the change of state, the EtherCAT slave copies current input data into the associated DP- RAM areas of the EtherCAT slave controller (ECSC). EK1110, EK1110-0008 Version: 2.6...
  • Page 24 In the Boot state the slave firmware can be updated. The Boot state can only be reached via the Init state. In the Boot state mailbox communication via the file access over EtherCAT (FoE) protocol is possible, but no other mailbox communication and no process data communication. Version: 2.6 EK1110, EK1110-0008...

  • Page 25: Coe - Interface: Notes

    Basics communication CoE - Interface: notes This device has no CoE. Detailed information on the CoE interface can be found in the EtherCAT system documentation on the Beckhoff website. EK1110, EK1110-0008 Version: 2.6...

  • Page 26: Distributed Clock

    4.2 seconds) • The EtherCAT master automatically synchronizes the local clock with the master clock in the EtherCAT bus with a precision of < 100 ns. For detailed information please refer to the EtherCAT system description. Version: 2.6 EK1110, EK1110-0008...

  • Page 27: Mounting And Wiring

    • Each assembly must be terminated at the right hand end with an EL9011 or EL9012 bus end cap, to ensure the protection class and ESD protection. Fig. 9: Spring contacts of the Beckhoff I/O components EK1110, EK1110-0008 Version: 2.6...

  • Page 28: Explosion Protection

    80°C at the wire branching points, then cables must be selected whose temperature data correspond to the actual measured temperature values! • Observe the permissible ambient temperature range of 0 to 55°C for the use of Beckhoff fieldbus components standard temperature range in potentially explosive areas! •...

  • Page 29: Atex - Special Conditions (Extended Temperature Range)

    80°C at the wire branching points, then cables must be selected whose temperature data correspond to the actual measured temperature values! • Observe the permissible ambient temperature range of -25 to 60°C for the use of Beckhoff fieldbus components with extended temperature range (ET) in potentially explosive areas! •...

  • Page 30: Continuative Documentation For Atex And Iecex

    Pay also attention to the continuative documentation Ex. Protection for Terminal Systems Notes on the use of the Beckhoff terminal systems in hazardous areas according to ATEX and IECEx, that is available for download within the download area of your product on the Beckhoff homepage www.beckhoff.com!

  • Page 31: Ul Notice

    Beckhoff EtherCAT modules are intended for use with Beckhoff’s UL Listed EtherCAT System only. CAUTION Examination For cULus examination, the Beckhoff I/O System has only been investigated for risk of fire and electrical shock (in accordance with UL508 and CSA C22.2 No. 142). CAUTION For devices with Ethernet connectors Not for connection to telecommunication circuits.

  • Page 32: Installation On Mounting Rails

    To mount the mounting rails with a height of 7.5 mm under the terminals and couplers, you should use flat mounting connections (e.g. countersunk screws or blind rivets). Version: 2.6 EK1110, EK1110-0008...
  • Page 33 PE power contact The power contact labeled PE can be used as a protective earth. For safety reasons this contact mates first when plugging together, and can ground short-circuit currents of up to 125 A. EK1110, EK1110-0008 Version: 2.6...
  • Page 34 Power Feed Terminals can be released and pulled at least 10 mm from the group of terminals. WARNING Risk of electric shock! The PE power contact must not be used for other potentials! Version: 2.6 EK1110, EK1110-0008...

  • Page 35: Installation Instructions For Enhanced Mechanical Load Capacity

    • Use countersunk head screws to fasten the mounting rail • The free length between the strain relief and the wire connection should be kept as short as possible. A distance of approx. 10 cm should be maintained to the cable duct. EK1110, EK1110-0008 Version: 2.6...

  • Page 36: Installation Positions

    Other installation positions All other installation positions are characterized by different spatial arrangement of the mounting rail - see Fig Other installation positions. The minimum distances to ambient specified above also apply to these installation positions. Version: 2.6 EK1110, EK1110-0008...
  • Page 37 Mounting and wiring Fig. 14: Other installation positions EK1110, EK1110-0008 Version: 2.6...

  • Page 38: Connection

    Insert the new component and plug in the connector with the wiring. This reduces the installation time and eliminates the risk of wires being mixed up. The familiar dimensions of the terminal only had to be changed slightly. The new connector adds about 3 mm. The maximum height of the terminal remains unchanged. Version: 2.6 EK1110, EK1110-0008...
  • Page 39 Ultrasonically “bonded” (ultrasonically welded) conductors Ultrasonically “bonded” conductors It is also possible to connect the Standard and High Density Terminals with ultrasonically “bonded” (ultrasonically welded) conductors. In this case, please note the tables concerning the wire-size width [} 40]! EK1110, EK1110-0008 Version: 2.6...

  • Page 40: Wiring

    The cables are released, as usual, using the contact release with the aid of a screwdriver. See the following table for the suitable wire size width. Version: 2.6 EK1110, EK1110-0008...

  • Page 41: Shielding

    0.14 ... 0.75 mm Wire size width (ultrasonically “bonded" conductors) only 1.5 mm (see notice [} 39]) Wire stripping length 8 ... 9 mm 4.7.3 Shielding Shielding Encoder, analog sensors and actuators should always be connected with shielded, twisted paired wires. EK1110, EK1110-0008 Version: 2.6...

  • Page 42: M8 Connector Cabling

    A list of the EtherCAT cable, power cable, sensor cable, Ethernet-/EtherCAT connectors and the field assembled connectors can be found at the following link: https://www.beckhoff.com/en-us/products/i-o/ accessories/ You can find the corresponding data sheets at the following link: https://www.beckhoff.com/en-us/support/ download-finder/data-sheets/ EtherCAT cable Fig. 19: ZK1090-3131-0xxx...
  • Page 43 Mounting and wiring M8 Connector pin assignment Signal Description Pin (M8) Transmit Data+ Transmit Data- Receive Data+ Receive Data- Shield Shielding Housing EK1110, EK1110-0008 Version: 2.6...

  • Page 44: Nut Torque For Connectors

    Mounting and wiring Nut torque for connectors For usage of the EtherCAT connector M8 of EK1110-0008 the following have to be noticed: M8 connectors It is recommended to pull the M8 connectors tight with a nut torque of 0.4 Nm. When using the torque control screwdriver ZB8800 is also a max.

  • Page 45: Positioning Of Passive Terminals

    The passive terminals have no current consumption out of the E-Bus. To ensure an optimal data transfer, you must not directly string together more than two passive terminals! Examples for positioning of passive terminals (highlighted) Fig. 21: Correct positioning Fig. 22: Incorrect positioning EK1110, EK1110-0008 Version: 2.6...

  • Page 46: Disposal

    Products marked with a crossed-out wheeled bin shall not be discarded with the normal waste stream. The device is considered as waste electrical and electronic equipment. The national regulations for the disposal of waste electrical and electronic equipment must be observed. Version: 2.6 EK1110, EK1110-0008...

  • Page 47: Commissioning

    System Manager TwinCAT tree Enter the EK1110/ EK1110-0008 as an EtherCAT (Direct mode) device in the TwinCAT System Manager in Config mode under Devices. Any Terminals already connected to the network can also be read. This will cause all the Bus Couplers with Bus Terminals and their configurations to be loaded. You can then adapt these to meet your requirements.
  • Page 48 Initialization error occurred 0x010_ Slave not present 0x020_ Slave signals link error 0x040_ Slave signals missing link 0x080_ Slave signals unexpected link 0x100_ Communication port A 0x200_ Communication port B 0x400_ Communication port C 0x800_ Communication port D Version: 2.6 EK1110, EK1110-0008...

  • Page 49: Error Handling And Diagnostics

    Error handling and diagnostics Error handling and diagnostics Diagnostic LED Fig. 25: EK1110/ EK1110-0008 LEDs for fieldbus diagnostics Display State Description LINK / ACT gree no connection on the EtherCAT strand (X1) linked EtherCAT device connected flashing active Communication with EtherCAT device...

  • Page 50: Appendix

    Appendix Appendix EtherCAT AL Status Codes For detailed information please refer to the EtherCAT system description. Version: 2.6 EK1110, EK1110-0008...

  • Page 51: Firmware Compatibility

    Appendix Firmware compatibility The EK1110 has no firmware. EK1110, EK1110-0008 Version: 2.6...

  • Page 52: Firmware Update El/Es/Em/Elm/Epxxxx

    NOTE Only use TwinCAT 3 software! A firmware update of Beckhoff IO devices must only be performed with a TwinCAT 3 installation. It is recommended to build as up-to-date as possible, available for free download on the Beckhoff website https://www.beckhoff.com/en-us/.

  • Page 53: Device Description Esi File/Xml

    The device revision is closely linked to the firmware and hardware used. Incompatible combinations lead to malfunctions or even final shutdown of the device. Corresponding updates should only be carried out in consultation with Beckhoff support. Display of ESI slave identifier...
  • Page 54 In this example in Fig. Change dialog, an EL3201-0000-0017 was found, while an EL3201-0000-0016 was configured. In this case the configuration can be adapted with the Copy Before button. The Extended Information checkbox must be set in order to display the revision. Version: 2.6 EK1110, EK1110-0008...
  • Page 55 Most EtherCAT devices read a modified ESI description immediately or after startup from the INIT. Some communication settings such as distributed clocks are only read during power-on. The EtherCAT slave therefore has to be switched off briefly in order for the change to take effect. EK1110, EK1110-0008 Version: 2.6...

  • Page 56: Firmware Explanation

    • offline: The EtherCAT Slave Information ESI/XML may contain the default content of the CoE. This CoE directory can only be displayed if it is included in the ESI (e.g. “Beckhoff EL5xxx.xml”). The Advanced button must be used for switching between the two views.
  • Page 57 Appendix Fig. 33: Firmware Update Proceed as follows, unless instructed otherwise by Beckhoff support. Valid for TwinCAT 2 and 3 as EtherCAT master. • Switch TwinCAT system to ConfigMode/FreeRun with cycle time >= 1 ms (default in ConfigMode is 4 ms). A FW-Update during real time operation is not recommended.

  • Page 58: Fpga Firmware *.Rbf

    The TwinCAT System Manager indicates the FPGA firmware version. Click on the Ethernet card of your EtherCAT strand (Device 2 in the example) and select the Online tab. The Reg:0002 column indicates the firmware version of the individual EtherCAT devices in hexadecimal and decimal representation. Version: 2.6 EK1110, EK1110-0008...
  • Page 59 Fig. 35: Context menu Properties The Advanced Settings dialog appears where the columns to be displayed can be selected. Under Diagnosis/Online View select the '0002 ETxxxx Build' check box in order to activate the FPGA firmware version display. EK1110, EK1110-0008 Version: 2.6...
  • Page 60 Older firmware versions can only be updated by the manufacturer! Updating an EtherCAT device The following sequence order have to be met if no other specifications are given (e.g. by the Beckhoff support): • Switch TwinCAT system to ConfigMode/FreeRun with cycle time >= 1 ms (default in ConfigMode is 4 ms).
  • Page 61 • In the TwinCAT System Manager select the terminal for which the FPGA firmware is to be updated (in the example: Terminal 5: EL5001) and click the Advanced Settings button in the EtherCAT tab: • The Advanced Settings dialog appears. Under ESC Access/E²PROM/FPGA click on Write FPGA button: EK1110, EK1110-0008 Version: 2.6...

  • Page 62: Simultaneous Updating Of Several Ethercat Devices

    The firmware and ESI descriptions of several devices can be updated simultaneously, provided the devices have the same firmware file/ESI. Fig. 37: Multiple selection and firmware update Select the required slaves and carry out the firmware update in BOOTSTRAP mode as described above. Version: 2.6 EK1110, EK1110-0008...

  • Page 63: Support And Service

    Please contact your Beckhoff branch office or representative for local support and service on Beckhoff products! The addresses of Beckhoff's branch offices and representatives round the world can be found on her internet pages: www.beckhoff.com You will also find further documentation for Beckhoff components there.
