Led Displays - Beckhoff BK5200 Documentation

Parameterization and Commissioning
5.4.1

LED displays

Module Status MS
LED
RUN green LED blinks
green LED is steadily lit
OVERFL red LED blinks
red LED is steadily lit
Network Status NS
LED
CONNECT green LED blinks
BUS OFF green LED is steadily lit
red LED blinks
red LED is steadily lit
I/O Status
LED
I/O RUN green LED is lit
I/O ERR red LED is lit
I/O ERR red LED blinks
38
Meaning
Configuration is incorrect
Status is OK
K-bus error
Receive queue overflow
Meaning
Bus Coupler is ready for communication, but not yet assigned
to the master
Bus Coupler is assigned to the master, data is being
exchanged
Timeout on I/O connection
BUS OFF: CAN error, devices have identical node address
Meaning
The Bus Terminals are working correctly
I/O error, a Bus Terminal or an internal K-bus with a fault
The Bus Terminals are being configured
Version: 2.0.0 BK52x0 and LC5200
