Victoria Arduino Adonis+ 2 Gr Technical Manual page 82

a group is not delivering, the area is empty.
Here below is an example: unit 1 is delivering (it has
just started and 0 seconds have passed); unit 2 has
been delivering for 12 seconds and unit 4 is deliver-
ing (it has been delivering for 21 seconds).
Area reserved to the
delivery time of unit 2
THURSDAY
0 I 12 I
Area reserved to the
delivery time of unit 1
SETTING THE SET POINT PRESS
The set point allows to chose the pressure/ temperature
in the working status.
SETPOINT PRESS
80
When the ENTER
read
:
Area reserved to the Press
delivery time of unit 3 Press ENTER to confirm and pass to the next step.
Press RESET to return to the previous page without
confirming.
12:00
I 21 PRESSURE - TEMPERATURE TABLE
Area reserved to the
Bar
delivery time of unit 4
0,50
0,55
0,60
0,65
0,70
0,75
0,80
0,85
key is pressed, the display will
SETPOINT PRESS
XX.XX BAR
to adjust the work-press/temp point.
°C °F
110,5 230,9
111,5 232,7
112,5 234,5
113,5 236,3
114 237,2
115 239
115,5 239,9
116,5 241,7
0,90 117,5
0,95 118
1,00 119
1,05 119,5
1,10 120,5
1,15 121
1,20 122
1,25 112,5
1,30 123
Bar °C
1,35 124
1,40 124,5
1,45 125
1,50 126
1,55 126,5
1,60 127
HISTORICAL ALARM VISUALISATION
The display will read:
FAULTS HISTORY
243,5
244,4
246,2
247,1
248,9
249,8
251,6
252,5
253,4
°F
255,2
256,1
257
258,8
