5.3 HOT WATER ECONOMISER
ADJUSTMENT
NOTE
This operation can be carried out while the machine
is turned on.
All models are equipped with a hot water
mixer tap which adjusts the water temperature and optimises
the system's performance.
To adjust the hot water economiser, turn the registration
knob.
The hot water economiser is located inside the
machine.
60
To access the economiser, remove the cup warm-
er section on the left by loosening the two screws
"D" as illustrated in the following figure.
D
Turn the adjustment knob ANTICLOCKWISE /
CLOCKWISE to INCREASE / REDUCE the tempera-
ture of the hot water;
Fig. 12
when the operation has been completed, screw
the protective panel back on.
Fig. 13
