6.7 ADJUSTING THE AUTOSTEAM
NOZZLE
(If Fitted)
To increase/reduce the amount of air injected into the
milk from the TurboCream nozzle (and therefore to
increase/reduce the amount of foam in the heated milk)
proceed as illustrated in Fig. 18:
① Loosen the stainless steel tube (1) as illustrated in
Fig. 18.A.
② To increase/reduce the amount of air, tighten (turn-
ing clockwise) or loosen (turning anticlockwise) the
Teflon tube (2) as illustrated in Fig. 18.B.
③ Tighten the stainless steel tube again.
66
Fig. 18.A
1
2
Fig. 18.B
④ As far as concerns temperature settings, see the
relevant programming section.
NOTE
By reducing or increasing the length (tightening or
loosening) the tube/Teflon tube by a few fractions of a
mm/mm, there is a significant difference in the amount
of foam in the heated milk.
Fig. 18
