Confirm by pressing the ENTER key.
Once the hours and the minutes have been varied
press ENTER again and vary the day, the month
and the year by using the same procedure as de-
scribed above.
On completion press ENTER to go on to the next
page.
DISPLAY (AND DELIVERY TIME) SETTING
(T3 version only)
On the main menu, it is possible to see the temperatures
of the units on the machine. The temperatures are given
in both in °C and °F. The first line shows the tempera-
tures for units 1 and 3, while the second line shows the
temperatures of units 2 and 4 or just the temperature for
unit 2, if there are just 3 units on the machine.
The function is opened by pressing the ENTER key and
the display will read "TEMP. DISPLAY".
Using the keys it is possible to select "ACTIVE" or
"NOT ACTIVE". The ENTER and RESET keys serve to
confirm in the following cases:
If "ACTIVE" is selected, this returns to the main
78
menu.
If "NOT ACTIVE" is selected, this opens the "DELIV-
ERY TIME" function (described here below).
The display will read:
GRINDING
When the ENTER key is pressed, the display will
read:
GRINDING
XXX
Using the keys, it is possible to select XXX as:
NOT ACTIVE (pouring times will not be shown).
ROW 1 (pouring times will be shown in row 1).
ROW 2 (pouring times will be shown in row 2).
Press ENTER to confirm and pass to the next step.
Press RESET to return to the previous page without
confirming.
If the delivery time display is on when a delivery is
started - unless with the Continuous function - the
bottom line of the display will show the delivery time
(or times if more than one unit is delivering).
Each group has an area of the bottom line: the area
on the left is for unit 1; the area alongside it is for
unit 2 and so on, until the area on the far right, which
is for unit 4.
The different areas are separated by vertical bars; if
a group is not delivering, the area is empty.
Here below is an example: unit 1 is delivering (it has
just started and 0 seconds have passed); unit 2 has
been delivering for 12 seconds and unit 4 is deliver-
ing (it has been delivering for 21 seconds).
Area reserved to the
Area reserved to the
delivery time of unit 2 delivery time of unit 3
THURSDAY 12:00
0 I 12 I I 21
Area reserved to the Area reserved to the
delivery time of unit 1
delivery time of unit 4
