3.3 Distress alert received unit, IC-305 and
ALARM unit, IC-306
Fig.3.3.1 IC-305:Distress alert received unit
Fig.3.3.3 IC-306:ALARM unit
16P0213A
Fig.3.3.2 IC-305 with panel removed
16P0213B
Fig.3.3.4 IC-306 with panel removed
3-10
3.3 IC-305 and IC-306
S2
S1
S3
S2
S1
S3
JP1: short
JP2: short
JP1
JP2
