3.1 Terminal unit, IC-215
Color LCD
FDD
(For 2HD and 2DD)
[D-GPS]
(L-band)
[ANT]
[POWER]
(12 V to 24 V)
Chapter 3. Location of Parts
320
Fig.3.1.1 Terminal unit, front view
[JUNCTION]
[PRINTER]
Fig.3.1.2 Terminal unit, rear view
3-1
Distress alert button
Power switch
[DTE]
[KEY BOARD]
[LAN]
(10BASE-T)
122
270
