AP4.6 Setting Active Port
Set "Active Port " and "Message Output Port" in "System Setup" menu to "ALL" and
"INT" respectively. (Keystroke: [F8][2]) The received message is saved in FELCOM
15 and then transferred to PC.
Procedure
1. Press [F8][2] to show "System Setup" menu.
2. Select "Active Port".
3. Select "ALL", followed by [Enter].
4. Select "Message Output Port".
5. Select "INT", followed by [Enter].
6. Press [Esc]. The "Update" window appears.
7. Select "Yes", followed by [Enter] to update the setting.
8. Press [Esc].
INT
Active Port
ALL
INT
EXT
Message
Output
INT+EXT
Port
AUTO
Table AP4.6.1 Active Port" and "Message Output Port
DTE and LAN ports are inactive.
DTE and LAN ports are active.
Received message is saved in the memory on FELCOM 15.
Received message is output from DTE and LAN ports.
Received message is saved in FELCOM 15 memory and output
from DTE and LAN ports at a time.
Received message is output according to Sub Address setting.
(Internal memory and LAN: 000; DTE: 001)
AP4-7
AP4.6 Setting Active Port
