ETC fos/4 Panel Quick Manual

ETC Quick Guide
fos/4 Panel

Overview

Use the images below as a guide to connect power and data and to navigate the basic features of the
fixture. For complete information, download the fos/4 Panel User Manual at etcconnect.com.
A
Large
(PL24 or PD24)
Accessory holder: Insert accessories into the two available slots from either side of the holder, and
A
then lock the holder (
Handles: For medium (PL16 or PD16) and large (PL24 or PD24) fixtures, carry the fixture by the pairs
B
of handles on the back of the fixture, and attach safety cables to handles when mounting the fixture.
Yoke tilt-lock: Tilt the fixture as needed, and then turn the tilt-lock clockwise to lock the position. If
C
necessary, press the center button on the tilt-lock to adjust the tilt-lock position.
Battery connector: Four-pin XLR connector for battery power (not available on PL24 or PD24).
D
Connect the fixture to battery power only when AC power is not available. Do not connect the fixture
to a battery and to AC power at the same time.
Power In and Power Thru connectors: powerCON
E
thru. The large fixture (PL24 or PD24) has a connector for power in only (no power thru connector).
User interface: View the fixture status, set the DMX address and mode, or set stand-alone options.
F
DMX In and DMX Thru connectors: Five-pin XLR connectors for DMX/RDM in and DMX/RDM thru.
G
Griprail: Attach standard accessories and mounting hardware to the back of the fixture using the
H
hardware provided with the accessories or using M6 standard T-nuts.
Safety cable attachment points: Small (PL8 or PD8) fixture only. For large and medium fixtures,
I
attach safety cables to handles ( B ), either the top pair or the bottom pair (
Corporate Headquarters Middleton, WI, USA +1 608 831 4116 London, UK +44 (0)20 8896 1000
Holzkirchen, DE +49 (80 24) 47 00-0 Rome, IT +39 (06) 32 111 683 Hong Kong +852 2799 1220 Paris, FR +33 1 4243 3535
Web
© 2020 Electronic Theatre Controls, Inc. Trademark and patent
Product information and specifications subject to change. ETC intends this document to be provided in its entirety.
7471M1300-1.0.0 Rev A Released 2020-01
B
C
B
A
H
Small
(PL8 or PD8)
page 5
).
etcconnect.com Support support.etcconnect.com
B
C
Medium
(PL16 or PD16)
D
E
I
®
TRUE1 TOP connectors for power in and power
Contact etcconnect.com/contactETC
info: etcconnect.com/ip
H
F
G
I
page 4
).
C
