Status Messages

7 Status Messages

7.1 Status Display

When the adjustable frequency drive is in status mode,
status messages are generated automatically and appear in
the bottom line of the display (see Figure 7.1).
7 7
Figure 7.1 Status Display
1 Operation Mode (see Table 7.2)
2 Reference Site (see Table 7.3)
3 Operation Status (see Table 7.4)
Table 7.1 Legend to Figure 7.1
60
Instruction Manual
Status
799RPM 7.83A
0.000
53.2%
Remote
Auto Ramping
Hand Local Stop
O
Running
Jogging
.
.
.
Stand by
1 2 3
Danfoss A/S © Rev. 2014-02-10 All rights reserved.

7.2 Status Message Definitions

Tables Table 7.2 to Table 7.4 define the meaning of the
displayed status messages.
Off
1(1)
36.4kW
Auto On
Table 7.2 Operation Mode
Remote
Local
Table 7.3 Reference Site
AC Brake
AMA finish OK
AMA ready
AMA running
Braking
Braking max.
Coast
The adjustable frequency drive does not react
to any control signal until [Auto On] or [Hand
On] is pressed.
The adjustable frequency drive is controlled
from the control terminals and/or the serial
communication.
The adjustable frequency drive can be
controlled by the navigation keys on the LCP.
Stop commands, reset, reversing, DC brake,
and other signals applied to the control
terminals can override local control.
The speed reference is given from external
signals, serial communication, or internal
preset references.
The adjustable frequency drive uses [Hand On]
control or reference values from the LCP.
AC Brake was selected in 2-10 Brake Function.
The AC brake over-magnetizes the motor to
achieve a controlled slow-down.
Automatic motor adaptation (AMA) was
carried out successfully.
AMA is ready to start. Press [Hand On] to start.
AMA process is in progress.
The brake chopper is in operation. Generative
energy is absorbed by the brake resistor.
The brake chopper is in operation. The power
limit for the brake resistor defined in
2-12 Brake Power Limit (kW) has been reached.
•
Coast inverse was selected as a function
for a digital input (parameter group 5-1*
Digital Inputs). The corresponding terminal
is not connected.
•
Coast activated by serial communication.
