User Interface

4.2 Backup and Copying Parameter Settings

Programming data is stored internally in the adjustable
frequency drive.
•
The data can be uploaded into the LCP memory
as a storage backup.
•
Once stored in the LCP, the data can be
downloaded back into the adjustable frequency
drive.
•
Data can also be downloaded into other
adjustable frequency drives by connecting the
LCP into those units and downloading the stored
settings. (This is a quick way to program multiple
units with the same settings).
•
Initialization of the adjustable frequency drive to
restore factory default settings does not change
data stored in the LCP memory.
WARNING
UNINTENDED START!
When the adjustable frequency drive is connected to AC
line power, the motor may start at any time. The
adjustable frequency drive, motor, and any driven
equipment must be in operational readiness. Failure to
be in operational readiness when the adjustable
frequency drive is connected to AC line power could
result in death, serious injury, or equipment or property
damage.

4.2.1 Uploading Data to the LCP

1. Press [Off] to stop the motor before uploading or
downloading data.
2. Go to 0-50 LCP Copy.
3. Press [OK].
4. Select All to LCP.
5. Press [OK]. A progress bar shows the uploading
process.
6. Press [Hand On] or [Auto On] to return to normal
operation.
MG16E222
Instruction Manual

4.2.2 Downloading Data from the LCP

1.
2.
3.
4.
5.
6.

4.3 Restoring Default Settings

CAUTION
Initialization restores the unit to factory default settings.
Any programming, motor data, localization, and
monitoring records will be lost. Uploading data to the
LCP provides a backup before initialization.
Restoring the adjustable frequency drive parameter
settings back to default values is done by initialization of
the adjustable frequency drive. Initialization can be
through 14-22 Operation Mode or manually.
•
•
•
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
Press [Off] to stop the motor before uploading or
downloading data.
Go to 0-50 LCP Copy.
Press [OK].
Select All from LCP.
Press [OK]. A progress bar shows the
downloading process.
Press [Hand On] or [Auto On] to return to normal
operation.
Initialization using 14-22 Operation Mode does not
change adjustable frequency drive data such as
operating hours, serial communication selections,
personal menu settings, fault log, alarm log, and
other monitoring functions.
Using 14-22 Operation Mode is generally
recommended.
Manual initialization erases all motor,
programming, localization, and monitoring data
and restores factory default settings.
