8.4 Warning and Alarm Definitions

Table 8.2 defines whether a warning is issued before an alarm, and whether the alarm trips the unit or trip locks the unit.
No. Description
1 10 Volts low
2 Live zero error
4 Mains phase loss
5 DC link voltage high
6 DC link voltage low
7 DC overvoltage
8 DC undervoltage
9 Inverter overloaded
10 Motor ETR overtemperature
11 Motor thermistor overtemperature
12 Torque limit
13 Overcurrent
14 Ground fault
15 Hardware mismatch
16 Short Circuit
8 8
17 Control word timeout
18 Start Failed
23 Internal Fan Fault
24 External Fan Fault
25 Brake resistor short-circuited
26 Brake resistor power limit
27 Brake chopper short-circuited
28 Brake check
29 Drive overtemperature
30 Motor phase U missing
31 Motor phase V missing
32 Motor phase W missing
33 Inrush fault
34 Fieldbus communication fault
35 Out of frequency range
36 Mains failure
37 Phase Imbalance
38 Internal fault
39 Heatsink sensor
40 Overload of Digital Output Terminal 27
41 Overload of Digital Output Terminal 29
42 Overload of Digital Output On X30/6
42 Overload of Digital Output On X30/7
46 Pwr. card supply
47 24 V supply low
48 1.8 V supply low
49 Speed limit
50 AMA calibration failed
51 AMA check U
52 AMA low I
64
Instruction Manual
and I
nom nom
nom
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
Warning Alarm/ Alarm/ Parameter Reference
Trip Trip Lock
X
(X) (X) 6-01 Live Zero Timeout Function
(X) (X) (X) 14-12 Function at Mains Imbalance
X
X
X X
X X
X X
(X) (X) 1-90 Motor Thermal Protection
(X) (X) 1-90 Motor Thermal Protection
X X
X X X
X X X
X X
X X
(X) (X) 8-04 Control Timeout Function
X
X 14-53 Fan Monitor
X
(X) (X) 2-13 Brake Power Monitoring
X X
(X) (X) 2-15 Brake Check
X X X
(X) (X) (X) 4-58 Missing Motor Phase Function
(X) (X) (X) 4-58 Missing Motor Phase Function
(X) (X) (X) 4-58 Missing Motor Phase Function
X X
X X
X X
X X
X X
X X
X X
(X) 5-00 Digital I/O Mode, 5-01 Terminal 27 Mode
(X) 5-00 Digital I/O Mode, 5-02 Terminal 29 Mode
(X) 5-32 Term X30/6 Digi Out (MCB 101)
(X) 5-33 Term X30/7 Digi Out (MCB 101)
X X
X X X
X X
X (X) 1-86 Trip Speed Low [RPM]
X
X
X
