Status Messages
QStop
Ramping
Ref. high
Ref. low
Run on ref.
7 7
Run request
Running
Sleep Mode
Speed high
Speed low
Standby
Start delay
Start fwd/rev
Stop
62
Instruction Manual
The motor is decelerating using 3-81 Quick
Stop Ramp Time.
•
Quick stop inverse was chosen as a function
for a digital input (parameter group 5-1*
Digital Inputs). The corresponding terminal
is not active.
•
The quick stop function was activated via
serial communication.
The motor is accelerating/decelerating using
the active ramp-up/down. The reference, a
limit value or a standstill is not yet reached.
The sum of all active references is above the
reference limit set in 4-55 Warning Reference
High.
The sum of all active references is below the
reference limit set in 4-54 Warning Reference
Low.
The adjustable frequency drive is running in
the reference range. The feedback value
matches the setpoint value.
A start command has been given, but the
motor is stopped until a run permissive signal
is received via digital input.
The motor is driven by the adjustable
frequency drive.
The energy saving function is enabled. This
means that at present the motor has stopped,
but that it will restart automatically when
required.
Motor speed is above the value set in
4-53 Warning Speed High.
Motor speed is below the value set in
4-52 Warning Speed Low.
In Auto On mode, the adjustable frequency
drive will start the motor with a start signal
from a digital input or serial communication.
In 1-71 Start Delay, a delay starting time was
set. A start command is activated and the
motor will start after the start delay time
expires.
Start forward and start reverse were selected
as functions for two different digital inputs
(parameter group 5-1* Digital Inputs). The
motor will start in forward or reverse
depending on which corresponding terminal
is activated.
The adjustable frequency drive has received a
stop command from the LCP, digital input or
serial communication.
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
Trip An alarm occurred and the motor is stopped.
Once the cause of the alarm is cleared, the
adjustable frequency drive can be reset
manually by pressing [Reset] or remotely by
control terminals or serial communication.
Trip lock An alarm occurred and the motor is stopped.
Once the cause of the alarm is cleared, power
must be cycled to the adjustable frequency
drive. The adjustable frequency drive can then
be reset manually by pressing [Reset] or
remotely by control terminals or serial
communication.
Table 7.4 Operation Status
NOTICE!
In auto/remote mode, the adjustable frequency drive
requires external commands to execute functions.
