APPENDIX D - OUTPUT TYPES

NO. TYPE
0000 Not Used
0001 Fire
0002 Hold Up Any
0003 Intruder Any
0005 Misoperation Any
(Abort)
0006 Confirmed Any
0007 Tamper Any
0008 Duress
0009 HU Device Any
0010 Gas
0011 Set Fail
0012 Entry Deviation
0013 Secure Intruder Any
0014 Siren Any
0016 Strobe Any
0017 Omit Rearm Any
0018 Unconfirmed Any
0021 Exit Starts Any
0022 Final Set Any
0023 Strobe Set Fail
0025 Keyswitch disarmed
0026 Set with Omit
0028 Power Fault
0029 Confirmed Intruder Any
54
ACTIVE
(Permanently off )
At alarm
"At a HU or Duress alarm
(This includes keypad HU)"
At alarm, while system is disarmed
When system is silenced after any
'intruder' output is triggered
After two 'intruder' alarm activations
Any tamper alarm
At a Duress alarm (i.e. from a
keypad)
At alarm on a HU input only
At alarm
Pre-set time after start of exit time, if
exit procedure is not complete
When deviation from entry route
occurs, during entry time
At alarm, after exit time started,
until disarmed
When alarm live
When alarm live
Zone omitted if active (or in
alarm condition) at the end of
confirmation time.
Any intruder alarm
When exit time starts to set FIRST
area
When FIRST area is set
Works similar to output 016, but also fires if the set fail timer expires.
This output turns on for 5 seconds when the system is disarmed via a
keyswitch input (pulsed or latched)
Activates when inputs are omitted on arming
Active during low volts and battery faults*. Restores at code entry after
fault cleared.
When more than one intruder
alarm activates
ENFORCER V11 PROGRAMMING GUIDE
RESTORE
When a valid code is entered
When a valid code is entered
At first valid code entry and at end
of confirm time.
After 2 minutes
At next code entry
At code entry to silence And at end
of confirm time.
When a valid code is entered
When a valid code is entered
When a valid code is entered
At code entry to rearm
At code entry to disarm
At first valid code entry and at end
of confirm time.
When alarm silenced or when siren
timer expires
When alarm silenced or when
strobe timer expires
When system disarmed
At code entry to silence
At code entry to unset LAST area
At code entry to disarm LAST area
At next code entry
