VLT AutomationDrive EtherNet/IP

Parameters

(8-01) Control Site
Option:
*Digital and control word
Digital only
Control word only
Function:
Select Digital and ctrl. word [0] for control
using both digital input and control word.
Select Digital only [1] for control using digital
inputs only.
Select Control word only [2] for control using
control word only.
The setting in this parameter overrules the
settings in par. 8-50 to 8-56.
(8-02) Control Word Source
Option:
None
FC RS485
FC USB
*Option A
Option B
Option C0
Option C1
Function:
Select the source of the control word: one of
two serial interfaces or four installed options.
This parameter must be set to [3] Option A to
enable control from the EtherNet/IP option.
This parameter cannot be adjusted while the
motor is running.
[0]
[1]
[2]
[0]
[1]
[2]
[3]
[4]
[5]
[6]
MG.90.Jx.02 ver. 5 th September 2007 – VLT is a registered Danfoss trademark
(8-03) Control Word Timeout Time
Range:
0.1 - 18000.0 s
* 1.0 s
Function:
Enter the maximum time expected to pass
between the reception of two consecutive
telegrams (containing a CTW). If this time is
exceeded, it indicates that the serial
communication has stopped. The function
selected in par. 8-04 Control Word Time-out
Function will then be carried out.
(8-04) Control Word Timeout
Function
Option:
*Off
Freeze Output
Stop
Jogging
Max. Speed
Stop and trip
Select set-up 1
Select set-up 2
Select set-up 3
Select set-up 4
Function:
Select the time-out function. The time-out
function activates if the following CTW fails to
be updated within the time period specified in
par. 8-03 Control Word Time-out Time.
- Off [0]: Resume control via serial bus
(Fieldbus or standard) using the most recent
control word.
[0]
[1]
[2]
[3]
[4]
[5]
[7]
[8]
[9]
[10]
32
