VLT AutomationDrive EtherNet/IP

LED Behaviour

The option LED's operates according to ODVA specifications.
MS: Module Status
State
No power
Device
Green: █████████████
operational
Standby
Green: ▂█▂█▂█▂█▂█▂█▂
Minor fault
Red: ▂█▂█▂█▂█▂█▂█▂█
Major fault
Red: ██████████████
Red: ▂█▂█▂█▂█▂█▂█▂█
Self test
Green: ▂█▂█▂█▂█▂█▂█▂
NS1 + NS2: Network status (one per port)
State
No IP-address
(no power)
No connections Green: ▂█▂█▂█▂█▂█▂█
Connected Green: ████████████
Connection
Red: ▂█▂█▂█▂█▂█▂█▂
time-out
Duplicate IP
Red: █████████████
Red: ▂█▂█▂█▂█▂█▂█▂█
Self test
Green: ▂█▂█▂█▂█▂█▂█▂
During normal operation the both the MS and at least one NS LED will light steady
LED
LED
