VLT AutomationDrive EtherNet/IP
(12-1*) Ethernet Link Parameters
[0] Port 1
[1] Port 2
- applies for whole parameter group.
(12-10) Link Status
Option:
*No link
Link
Function:
Read only.
Displays the link status of the Ethernet ports.
(12-11) Link Duration
Option:
Link Duration Port 1
Function:
Read only.
Displays the duration of the present link on
each port in dd:hh:mm:ss.
(12-12) Auto Negotiation
Option:
Off
*On
Function:
Configures Auto Negotiation of Ethernet link
parameters, for each port: ON or OFF.
If set to OFF, Link Speed and Link Duplex can
configured in par. 12-13 and 12-14.
(12-13) Link Speed
Option:
*None
10 Mbps
100 Mbps
Function:
Forces the link speed for each port in 10 or 100
Mbps.
If par. 12-12 is set to: ON, this parameter is
read only and displays the actual link speed.
"None" is displayed if no link is present.
- P a r a m e t e r s –
[0]
[1]
(dd:hh:mm:ss)
[0]
[1]
[0]
[1]
[2]
MG.90.Jx.02 ver. 5 th September 2007 – VLT is a registered Danfoss trademark
(12-14) Link Duplex
Option:
Half Duplex
*Full Duplex
Function:
Forces the duplex for each port to Full or Half
duplex.
If par. 12-12 is set to: ON, this parameter is
read only.
[0]
[1]
