VLT AutomationDrive EtherNet/IP
Class ID 0x06 Connection Manager
Instance Attributes
Attribute Access
1 Get
2 Get
3 Get
4 Get
5 Get
6 Get
7 Get
8 Get
9 Get
Class ID 0x28 Motor Data Object
Instance Attributes
Attribute Access
1 Get
2 Get
3 Get/Set
6 Get/Set
7 Get/Set
8 Get/Set
9 Get/Set
12 Get/Set
15 Get/Set
N.B.
Class ID 0x28 is only available if ODVA profile is selected in par. 8-10.
MG.90.Jx.02 ver. 5
Name
Open Requests
Open Format Rejects
Open Resource Rejects
Open Other Rejects
Close Requests
Close Format Requests
Close Other Requests
Connection Timeouts
Connection Entry List
NumConnEntries
ConnOpenBits
Name Data Type
Number of Attributes
supported
List of attributes
supported
Motor Type
Rated Current
Rated Voltage
Rated Power
Rated Frequency
Pole Count
Base Speed
th
September 2007 – VLT is a registered Danfoss trademark
Data Type
UINT Number of Forward Open requests
received
UINT Number of Forward Open requests
rejected due to bad format
UINT Number of Forward Open requests
rejected due to lack of resources
UINT Number of Forward Open requests
rejected due to other reasons
UINT Number of Forward Close requests
received
UINT Number of Forward Close requests
rejected due to bad format
UINT Number of Forward Close requests
rejected due to other reasons
UINT Number of connection timeouts
Struct of:
INT Number of connection entries
ARRAY of List of connection data
BOOL
Parameter
USINT -
Array of -
USINT
USINT 1-10
UINT 1-24
UINT 1-22
UDINT 1-20
UINT 1-23
UINT 1-39
UINT 1-25
Description
Description
7
3,6,7,8,9,12,15
3: PM sync. motor (FC 302 only)
7: Squirrel cage induction motor
Unit: 100 mA
Unit: Volt
Unit: Watt
Unit: Hertz
Number of poles in motor
Unit: RPM
