Danfoss VLT AutomationDrive Manual page 48

®
VLT AutomationDrive EtherNet/IP
Bit Warning word 2
(Par 16-93)
(Hex)
00000001 Start Delayed
00000002 Stop Delayed
00000004 Clock Failure
00000008 Firemode was active
00000010
00000020 No Flow
00000040 Dry Pump
00000080 End of Curve
00000100 Broken Belt
00000200 Discharge high
00000400
00000800
00001000
00002000
00004000
00008000
00010000
00020000 KTY warning
00040000 Fans warning
00080000 ECB warning
00100000
00200000
00400000
00800000
01000000
02000000
04000000
08000000
10000000
20000000
40000000 PTC thermistor
80000000
MG.90.Jx.02 ver. 5
- T r o u b l e s h o o t i n g -
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
th
September 2007 – VLT is a registered Danfoss trademark
Bit Extended status word
(Par 16-94)
(Hex) FC 100 only !!
00000001 Ramping
00000002 AMA Running
00000004 Start CW/CCW
00000008 Slow Down
00000010 Catch Up
00000020 Feedback high
00000040 Feedback low
00000080 Output current high
00000100 Output current low
00000200 Output frequency high
00000400 Output frequency low
00000800 Brake check OK
00001000 Braking max
00002000 Braking
00004000 Out of speed range
00008000 OVC active
00010000 AC brake
00020000 Password Timelock
00040000 Password Protection
00080000 Reference high
00100000 Reference low
00200000 Local Ref./Remote Ref.
00400000
00800000
01000000
02000000
04000000
08000000
10000000
20000000
40000000
80000000
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
