VLT AutomationDrive EtherNet/IP
Setting up drive with automatic (BOOTP/DHCP) assigned IP address:
Par. Name
12-00 IP Address Assignment
12-01 IP Address
12-02 Subnet Mask
12-03 Default Gateway
By IP address assigned by DHCP/BOOTP server, the assigned IP Address and Subnet Mask can be
read out in par. 12-01 and 12-02.
In par. 12-04 DHCP Server, the IP address of the found DHCP or BOOTP server is displayed.
For DHCP only: The remaining lease-time can be read-out in par. 12-05 Lease Expires.
Par. 12-09 Physical Address reads out the MAC address of option, which is also printed on the label
of the option. If using fixed leases together with DHCP or BOOTP, the physical MAC address is linked
with a fixed IP address.
N.B.:
If no DHCP or BOOTP reply has been received after 4 attempts (e.g. if the DHCP/BOOTP server
has been powered off), the option will fallback to the last good known IP address.
Par. 12-03 Default Gateway is optional and only used in routed networks.
Par. 12-06 Name Servers
Par. 12-07 Domain Name
Par. 12-08 Host Name
Are used with Domain Name Server systems and are all optional. If DHCP or BOOTP is selected as IP
address assignment, these parameters are read only.
MG.90.Jx.02 ver. 5
Value
[1] DHCP/[2] BOOTP
Read only
Read only
Read only
th
