VLT AutomationDrive EtherNet/IP

Parameter List

PNU Parameter Name
8-0x
8-01 Control Site
8-02 Control Word Source
8-03 Control Word Timeout Time
8-04 Control Word Timeout
Function
8-05 End-of-timeout Function
8-06 Reset Control Word Timeout
8-07 Diagnosis Trigger
8-10 Control Word Profile
8-13 Configurable Status Word
8-5x
8-50 Coasting Select
8-51 Quick Stop Select
8-52 DC Brake Select
8-53 Start Select
8-54 Reversing Select
8-55 Set-up Select
8-56 Preset Reference Select
12-0x
12-00 IP Address Assignment
12-01 IP Address
12-02 Subnet Mask
12-03 Default Gateway
12-04 DHCP Server
12-05 Lease Expires
12-06 Name Servers
12-07 Domain Name
12-08 Host Name
12-09 Physical Address
12-1x
12-10 Link Status
12-11 Link Duration
12-12 Auto Negotiation
12-13 Link Speed
12-14 Link Duplex
12-2x
12-20 Control Instance
12-21 Process Data Config Write
12-22 Process Data Config Read
12-28 Store Data Values
12-29 Store Always
12-3x
12-30 Warning Parameter
12-31 Net Control
12-32 Net Reference
12-33 CIP Revision
12-34 CIP Product Code
12-37 COS Inhibit Timer
12-38 COS Filters
12-8x
12-80 FTP Server
12-81 HTTP Server
12-82 SMTP Service
12-89 Transp. Socket Channel Port
12-9x
12-90 Cable Diagnostics
12-91 Auto Cross-Over
12-92 IGMP Snooping
12-93 Cable Error Length
12-94 Broadcast Storm Protection
12-95 Broadcast Storm Filter
12-98 Interface Counters
12-99 Media Counters
MG.90.Jx.02 ver. 5
- P a r a m e t e r s –
Default value
Communication and options
Dig. and ctrl. word [0]
Option A [3]
1.0 s
Off [0]
Hold set-up [0]
Do not reset [0]
Disable [0]
FC profile [0]
Profile default [1]
Digital/Bus
Logic OR [3]
Logic OR [3]
Logic OR [3]
Logic OR [3]
Logic OR [3]
Logic OR [3]
Logic OR [3]
IP settings
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
00:00:00:00
0.0.0.0
-
-
00:1B:08:00:00:00
Ethernet Link Parameters
No Link [0]
00:00:00:00
On [1]
None [0]
Full Duplex [1]
Process Data
None
-
-
Off [0]
Off [0]
EtherNet/IP
0000 hex
Off [0]
Off [0]
00
0
0
0000
Other Ethernet Services
Disable [0]
Disable [0]
Disable [0]
Disable [0]
Advanced Ethernet Settings
Disable [0]
Enable [0]
Enable [0]
0
0
Enable [1]
0
0
th
September 2007 – VLT is a registered Danfoss trademark
Range Conv. Index
[0 - 2] -
[0 - 4] -
0.1 - 18000 -1
[0 - 10] -
[0 - 1] -
[0 - 1] -
[0 - 3] -
[0 - 5] -
[0 – 85] -
[0 - 3] -
[0 - 3] -
[0 - 3] -
[0 - 3] -
[0 - 3] -
[0 - 3] -
[0 - 3] -
0 - 255 -
0 – 255 -
0 – 255 -
0 - 255 -
0 - 255 -
- -
0 - 255 -
max. 19 ch. -
max. 19 ch. -
- -
[0 - 1] -
- -
[0 - 1] -
[0 - 2] -
[0 - 1] -
20 - 103 -
- -
- -
[0 – 1] -
[0 - 1] -
0000–FFFF -
[0 - 1] -
[0 - 1] -
0 – 99 -
9999 -
0 - 65535 0
0000-FFFF -
[0 – 1] -
[0 – 1] -
[0 – 1] -
[0 – 1] -
[0 - 1] -
[0 - 1] -
[0 - 1] -
0 - 200 0
Off – 20% -
[0 - 1] -
0 - 65535 -
0 - 65535 -
Data Type Array
Unsigned 8 -
Unsigned 8 -
Unsigned 32 -
Unsigned 8 -
Unsigned 8 -
Unsigned 8 -
Unsigned 8 -
Unsigned 8 -
Unsigned 8 [12-15]
Unsigned 8 -
Unsigned 8 -
Unsigned 8 -
Unsigned 8 -
Unsigned 8 -
Unsigned 8 -
Unsigned 8 -
Unsigned 8 -
Oct. string 4 -
Oct. string 4 -
Oct. string 4 -
Oct. string 4 -
Time diff. w/date -
Oct. string 4 -
Visible string 48 -
Visible string 48 -
Visible string 17 -
Unsigned 8 [0-1]
Time diff. w/date [0-1]
Unsigned 8 [0-1]
Unsigned 8 [0-1]
Unsigned 8 [0-1]
Unsigned 8 -
Unsigned 16 [0-9]
Unsigned 16 [0-9]
Unsigned 8 -
Unsigned 8 -
Unsigned 16 -
Unsigned 8 -
Unsigned 8 -
Unsigned 16 [0-1]
Unsigned 16 [0-1]
Unsigned 16 -
Unsigned 16 [0-9]
Unsigned 8 -
Unsigned 8 -
Unsigned 8 -
Unsigned 8 -
Unsigned 8 -
Unsigned 8 -
Unsigned 8 -
Unsigned 16 [0-1]
Unsigned 16 [0-1]
Unsigned 8 [0-1]
Unsigned 16 [0-10]
Unsigned 16 [0-11]
43
