VLT AutomationDrive EtherNet/IP
(12-30) Warning Parameter
Range:
0000 – FFFF hex
Function:
Read only.
Displays the EtherNet/IP specific 16-bit Status-
word.
Bit Description
0 Owned
1
2 Configured
3
4
5
6
7
8 Minor recoverable fault
9 Minor unrecoverable fault
10 Major recoverable fault
11 Major unrecoverable fault
12
13
14
15
(12-31) Net Reference
Option:
*Off
On
Function:
Read only.
Displays the reference source in Instance
21/71.
- Off: Reference from the network is not
active.
- On: Reference from the network is active.
(12-32) Net Control
Option:
*Off
On
Function:
Read only.
Displays the control source in Instance 21/71.
- Off: Control via the network is not active..
- On: Control via the network is active
- P a r a m e t e r s –
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
[0]
[1]
[0]
[1]
MG.90.Jx.02 ver. 5 th September 2007 – VLT is a registered Danfoss trademark
(12-33) CIP Revision
Range:
[0] Major version
[1] Minor version
Function:
Read only.
Displays the CIP-version of the option
software.
(12-34) CIP Product Code
Range:
0 – 9999
*1100 (FC 302)
*1110 (FC 301)
Function:
Read only.
Displays the CIP product code.
(12-37) COS Inhibit Timer
Range:
*0 – 65,535 ms
Function:
Read only
Change-Of-State inhibit timer.
If the option is configured for COS operation,
this inhibit timer can be configured in the
Forward Open telegram to prevent that
continuously changing PCD data generates
extensive network traffic.
The inhibit time is in milliseconds, 0 =
disabled.
(12-38) COS Filters
Range:
[0 - 9] Filter 0 – 9 (0000 - FFFFhex)
Function:
Change-Of-State PCD filters.
Sets up a filter mask for each word of process
data when operating in COS-mode.
Single bits in the PCD's can be filtered in/out.
(00 - 99)
(00 - 99)
