VLT AutomationDrive EtherNet/IP
- Freeze output [1]: Freeze output frequency
until communication resumes.
- Stop [2]: Stop with auto restart when
communication resumes.
- Jogging [3]: Run the motor at JOG frequency
until communication resumes.
- Max. freq.. [4]: Run the motor at maximum
frequency until communication resumes.
- Stop and trip[5]: Stop the motor, then reset
the frequency converter in order to restart: via
the fieldbus, via the reset button on the LCP or
via a digital input.
- Select set-up 1-4 [7] - [10]: This option
changes the set-up upon reestablishment of
communication following a control word time-
out. If communication resumes causing the
time-out situation to disappear, par. 8-05 End-
of-time-out Function defines whether to
resume the set-up used before the time-out or
to retain the set-up endorsed by the time-out
function. Note the following configuration
required in order to change the set-up after a
time-out: Set Par. 0-10 Active set-up to Multi
set-up [9], and select the relevant link in par.
0-12 This Set-up Linked To.
(8-05) End-of-timeout Function
Option:
*Hold set-up
Resume set-up
Function:
Select the action after receiving valid CTW
following a time-out. This parameter is active
only when par. 8-04 is set to Set-up 1-4.
Hold: The frequency converter retains the set-
up selected in par. 8-04 and displays a
warning, until par. 8-06 toggles. Then the
frequency converter resumes its original set-
up.
Resume: The frequency converter resumes the
set-up active prior to the time-out.
(8-06) Reset Control Word Timeout
Option:
*Do not reset
Do reset
Function:
Select Do reset [1] to return the frequency
converter to the original set-up following a
control word time-out. When the value is set to
Do reset [1], the frequency converter performs
the reset and then immediately reverts to the
Do not reset [0] setting.
- P a r a m e t e r s –
[0]
[1]
[0]
[1]
MG.90.Jx.02 ver. 5 th September 2007 – VLT is a registered Danfoss trademark
Select Do not reset [0] to retain the set-up
specified in par. 8-04 Select setup 1-4
following a control word time-out.
This parameter is active only when Hold set-up
[0] has been selected in par. 8-05 End- of-
Time-out Function.
(8-07) Diagnosis Trigger
Option:
*Disable
Trigger on alarms
Trigger on alarms/warn.
Function:
This parameter has no function for EtherNet/IP.
(8-10) Control Word Profile
Option:
*FC profile
ODVA
Function:
Select the interpretation of the control and
status words corresponding to the installed
fieldbus. Only the selections valid for the
fieldbus installed in slot A will be visible in the
LCP display.
(8-13) Configurable Status Word
Option:
No function
* Profile Default
Alarm 68 Only
Trip excl Alarm 68
T18 DI status
T19 DI status
T27 DI status
T29 DI status
T32 DI status
T33 DI status
T37 DI status
Thermal warning
Brake fault (IGBT)
Out of ref range
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Comparator 4
Comparator 5
Logic Rule 0
Logic Rule 1
Logic Rule 2
Logic Rule 3
Logic Rule 4
[0]
[1]
[2]
[0]
[5]
[0]
[1]
[2]
[3]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[21]
[30]
[40]
[60]
[61]
[62]
[63]
[64]
[65]
[70]
[71]
[72]
[73]
[74]
