How to Configure the System

IP Settings

All IP-related parameters are located in parameter group 12-0*:
12-00 IP Address Assignment
12-01 IP Address
12-02 Subnet Mask
12-03 Default Gateway
12-04 DHCP Server
The MCA121 option offers several ways of IP address assignment.
Setting up drive with manual assigned IP address:
Par. Name
12-00 IP Address Assignment
12-01 IP Address
12-02 Subnet Mask
12-03 Default Gateway
*= Class C IP address example. Any valid IP address can be entered.
N.B.:
A power-cycle is necessary after setting the IP parameters manually.
MG.90.Jx.02 ver. 5
12-05
12-06
12-07
12-08
12-09
Value
[0] MANUAL
192.168.0.xxx*
255.255.255.0*
optional
th
September 2007 – VLT is a registered Danfoss trademark
Lease Expires
Name Servers
Domain Name
Host Name
Physical Address
