VLT AutomationDrive EtherNet/IP
6 Set
7 Get
8 Get
9 Get
Services supported:
Service Supported
Code
Class Instance
01h Yes Yes
0Eh Yes Yes
10h - Yes
43h - Yes
Class ID 0x0F Parameter Object
Class attributes
Attribute Access
Rule
1 Get
2 Get
3 Get
8 Get
9 Get
10 Get/Set
MG.90.Jx.02 ver. 5
Single Collisions UDINT
Multiple Collisions UDINT
SQE Test Errors UDINT
Deferred UDINT
Transmissions
Late Collisions UDINT
Excessive UDINT
Collisions
MAC Transmit UDINT
Errors
Carrier Sense UDINT
Errors
Frame Too Long UDINT
MAC Receive UDINT
Errors
Interface Control STRUCT of:
Control Bits WORD
Forced Interface UINT
Speed
Interface Label SHORT_STRING
Link List Size USINT
Link List ARRAY OF UINT
Service Name
Get_Attribute_All
Get_Attribute_Single
Set_Attribute_Single
Get_and_Clear
Name Data
Type
Revision UINT
Max Instance UINT
Number of UINT
instances
Parameter WORD
Class
Descriptor
Configuration UINT
Assembly
Instance
Native Language USINT
th
September 2007 – VLT is a registered Danfoss trademark
Successfully transmitted frames
which experienced exactly one
collision
Successfully transmitted frames
which experienced more than
one collision
Number of times SQE test error
message is generated
Frames for which first
transmission attempt is delayed
because the medium is busy
Number of times a collision is
detected later than 512 bit times
into the transmission of a packet
Frames for which transmission
fails due to excessive collisions
Frames for which transmission
fails due to an internal MAC sub
layer transmit error
Times that the carrier sense
condition was lost or never
asserted when attempting to
transmit a frame
Frames received that exceed the
maximum permitted frame size
Frames for which reception on
an interface fails due to an
internal MAC sub layer receive
error
Configuration for physical
interface
Interface Control Bits
Speed at which the interface
shall be forced to operate Speed
in Mbps (10, 100, 1000, etc.)
Human readable identification
Number of members in Link List
Link List between internal and
all according external interfaces
Description of Service
Returns a predefined listing of this objects attributes
Returns the contents of the specified attribute.
Modifies a single attribute.
Gets then clears the specified attribute (Interface Counters or
Media Counters).
Description of Attribute
revision of object
max instance number
amount of instances
Parameter description
instance number of the configuration
assembly
Language ID for all character array accesses
12-99 [2]
12-99 [3]
12-99 [4]
12-99 [5]
12-99 [6]
12-99 [7]
12-99 [8]
12-99 [9]
12-99 [10]
12-99 [11]
-
-
-
-
-
-
Contents
01
variable
variable
0x03
0
variable
55
