VLT AutomationDrive EtherNet/IP
Class ID 0xF5 Interface Object
Instance Attributes
Access
Attribute
Rule
1 Get
2 Get
3 Get/Set
4 Get
5 Get/Set
6 Get/Set
Class ID 0xF6 Link Object
Three instances of the Link Object are implemented:
- Instance 1 and 2 relates to the physical Port 1 and 2 of the option.
- Instance 3 relates to the internal interface of the option, after the build-in switch.
Instance Attributes
Attribute Access
Rule
1 Get
2 Get
3 Get
4 Get
5 Get
MG.90.Jx.02 ver. 5
Name Data Type
Status DWORD
Configuration DWORD
Capability
Configuration DWORD
Control
Physical Link Object STRUCT of:
Path size UINT
Path Padded
EPATH
Interface STRUCT of:
Configuration
IP Address UDINT
Network Mask UDINT
Gateway Address UDINT
Name Server UDINT
Name Server 2 UDINT
Domain Name STRING
Host Name STRING
Name Data Type
Interface Speed UDINT
Interface Flags DWORD
Physical Address ARRAY of 6 USINTs
Interface Counters STRUCT of
In Octets UDINT
In Ucast Packets UDINT
In NUcast Packets UDINT
In Discards UDINT
In Errors UDINT
In Unknown Protos UDINT
Out Octets UDINT
Out Ucast Packets UDINT
Out NUcast UDINT
Packets
Out Discards UDINT
Out Errors UDINT
Media Counters STRUCT of:
Alignment Errors UDINT
FCS Errors UDINT
th
September 2007 – VLT is a registered Danfoss trademark
Description of Attribute
Interface status
Interface capability flags
Interface control flags
Path to physical link object
Size of Path
Logical segments identifying the
physical link object
TCP/IP network interface
configuration.
The device's IP address.
The device's network mask.
Default gateway address
Primary name server
Secondary name server
Default domain name
Host name
Description of Attribute
Interface speed in Mbps (e.g., 0,
10, 100, 1000, etc.)
Interface status flags
MAC layer address
Octets received on the interface
Unicast packets received on the
interface
Non-unicast packets received on
the interface
Inbound packets received on the
interface but discarded
Inbound packets that contain
errors (does not include In
Discards)
Inbound packets with unknown
protocol
Octets sent on the interface
Unicast packets sent on the
interface
Non-unicast packets sent on the
interface
Outbound packets discarded
Outbound packets that contain
errors
Media-specific counters
Frames received that are not an
integral number of octets in
length
Frames received that do not
pass the FCS check
Parameter In
Drive
-
-
-
-
-
-
-
12-01
12-02
12-03
12-06 [0]
12-06 [0]
12-07
12-08
Parameter in
drive
12-13
-
12-09
12-98 [0]
12-98 [1]
12-98 [2]
12-98 [3]
12-98 [4]
12-98 [5]
12-98 [6]
12-98 [7]
12-98 [8]
12-98 [9]
12-98 [10]
12-99 [0]
12-99 [1]
