VLT AutomationDrive EtherNet/IP
(12-00) IP Address Assignment
Option:
*Manual
DHCP
BOOPT
Function:
Selects the IP Address assignment method.
If Manual is selected, the IP-address can be set
in par. 12-01 IP Address.
(12-01) IP Address
Range:
*000.000.000.000 - 255.255.255.255
Function:
Configure the IP address of the option.
Read-only if par. 12-00 set to DHCP or
(12-02) Subnet Mask
Range:
*000.000.000.000 - 255.255.255.255
Function:
Configure the IP subnet mask of the option.
Read-only if par. 12-00 set to DHCP or BOOTP.
(12-03) Default Gateway
Range:
*000.000.000.000 – 255.255.255.255
Function:
Configure the IP default gateway of the option.
Read-only if par. 12-00 set to DHCP or BOOTP.
(12-04) DHCP Server
Option:
*000.000.000.000 – 255.255.255.255
Function:
Read only.
Displays the IP address of the found DHCP or
BOOTP server.
N.B.:
A power-cycle is necessary after setting
the IP parameters manually.
- P a r a m e t e r s –
[0]
[1]
[2]
BOOTP.
MG.90.Jx.02 ver. 5 th September 2007 – VLT is a registered Danfoss trademark
(12-05) Lease Expires
Option:
dd:hh:mm:ss
Function:
Read only.
Displays the lease-time left for the current
DHCP-assigned IP address.
(12-06) Name Servers
Option:
[0] Primary DNS
[1] Secondary DNS
Function:
IP addresses of Domain Name Servers.
Can be automatically assigned when using
DHCP.
(12-07) Domain Name
Option:
(Max. 19 chars.)
*blank
Function:
Domain name of the attached network.
Can be automatically assigned when using
DHCP.
(12-08) Host Name
Option:
(Max. 19 chars.)
*blank
Function:
Logical (given) name of option.
(12-09) Physical Address
Range:
00:1B:08:00:00:00 – 00:1B:08:FF:FF:FF
Function:
Read only
Displays the Physical (MAC) address of the
option.
*000.000.000.000
*000.000.000.000
