Technical Specifications

This chapter provides important technical specifications related to the device.
5.1

Power Supply Specifications

The RUGGEDCOM RX1400 includes one of the following internal power supplies:
Power Supply Type
a
(T) denotes time-delay fuse.
b
Power consumption varies based on the device configuration.
5.2

Failsafe Alarm Relay Specifications

Max Switching Voltage
Rated Switching Current
Maximum Switching Capacity
5.3

Fast Ethernet Port Specifications

The RUGGEDCOM RX1400 features four 10/100Base-TX fast Ethernet (FE) ports with
RJ45 connectors. For more information about the serial ports, refer to
Ports (Page
Speed
Connector
Duplex
Cable Type
RUGGEDCOM RX1400
Installation Manual, 01/2021, C79000-G8976-1103-17
HI
±48V VDC
12-24 VDC
±12-24 VDC
33)".
a
100 Mbps
RJ45
a
FDX/HDX
b
> CAT-5
Input Range Internal Fuse Rating
88-264 VAC
98-300 VDC
±36-72 VDC
9-36 VDC
±36 VDC
240 VAC
125 VDC
2 A @ 240 VAC
0.15 A @ 125 VDC
2 A @ 30 VDC
150 W
500 VA
Maximum Power
a
Consumption
3.15 A(T)
6.3 A(T)
"Fast Ethernet
5
b
< 15 W
