Antenna Type
ANT795-4MA Omni-
Directional
ANT795-4MC Omni-
Directional
ANT795-4MD Omni-
Directional
ANT795-4MX Omni-
Directional
ANT795-6DC Directional
b
ANT795-6MN Directional
Omni-
Directional
b
ANT795-6MT Directional
Omni-
Directional
a
Not for use in Canada.
b
Must always be used with a 5 m (16 ft) cable (6X1875-5CH50).
c
Total gain is 3.6 dBi when connected via a 5 m (16 ft) cable (6X1875-5CH50) with a 4.4 dB loss.
d
Must always be used with a 10 m (33 ft) cable (6X1875-5CN10).
e
Total gain is 9.2 dBi when connected via a 10 m (33 ft) cable (6X1875-5CN10) with an 8.8 dB loss.
f
Total gain is 9.1 dBi when connected via a 5 m (16 ft) cable (6X1875-5CH50) with a 4.4 dB loss.
g
Total gain is 2.6 dBi when connected via a 5 m (16 ft) cable (6X1875-5CH50) with a 4.4 dB loss.
2.5.3

Connecting LTE Antennas

Install a single 4G LTE (Long Term Evolution) antenna for Single-Input Single-Output
(SISO) or dual antennas for Multiple-Input Multiple-Output (MIMO).
To install an LTE antenna, do the following:
Radiation hazard – risk of Radio Frequency (RF) exposure.
Antennas must be placed at a distance of at least 35 cm (13.8 in) from all persons
during normal operation. The antennas used for this product must not be located
or operating in conjunction with any other antenna or transmitter, except in
accordance with FCC multi-transmitter evaluation procedures.
RUGGEDCOM RX1400
Installation Manual, 01/2021, C79000-G8976-1103-17
Operating Gain (dBi)
Frequency
(GHz)
2.4
5.0
2.4
5.0
2.4
5.0
2.4
5.0
2.4
a
5.0
2.4
a
5.0
2.4
a
5.0
WARNING
Article Number
3.0 6GK5795-4MA00-0AA0
5.0
3.0 6GK5795-4MC00-0AA0
5.0
3.0 6GK5795-4MD00-0AA0
5.0
2.0 6GK5795-4MX00-0AA0
2.5
9.0 6GK5795-6DC00-0AA0
6.0 6GK5795-6MN10-0AA6
c
8.0
5.0 6GK5795-6MT00-0AA0
g
7.0
Installing the Device
2.5.3 Connecting LTE Antennas
Reference
https://
support.industry.siemens.com/
cs/ww/en/view/61199227
https://
support.industry.siemens.com/
cs/ww/en/view/61199227
https://
support.industry.siemens.com/
cs/ww/en/view/61199227
https://
support.industry.siemens.com/
cs/ww/en/view/102325861
https://
support.industry.siemens.com/
cs/ww/en/view/60510336
https://
support.industry.siemens.com/
cs/ww/en/view/26536615
https://
support.industry.siemens.com/
cs/ww/en/view/60510908
