Communication Ports

The RUGGEDCOM RX1400 can be equipped with various types of communication
ports to enhance its abilities and performance.
1
2
1
2
3
4
5
6
7
8
9
Figure 4.1
Note
For information about the LTE MAIN, LTE MIMO or GPS ports and the cellular
modem, refer to
4.1

Fast Ethernet Ports

The RUGGEDCOM RX1400 features four 10/100Base-TX fast Ethernet (FE) ports with
RJ45 connectors. The RJ45 connectors are directly connected to the chassis ground
on the device and can accept CAT-5 shielded twisted-pair (STP) cables.
For technical specifications, refer to
RUGGEDCOM RX1400
Installation Manual, 01/2021, C79000-G8976-1103-17
Serial Ports
Access Plate
ANT1 Port
Fast Ethernet Ports
ANT2 Port
SFP Transceiver Ports
ANT3 Port
ANT4 Port
ANT5 Port
Port Assignment
"Cellular Modem Specifications (Page
3
4
5
6
7
8
9
"Fast Ethernet Port Specifications (Page
40)".
4
39)".
