3.4
Inserting/Removing the MicroSD Card
The RUGGEDCOM RX1400 accepts a microSD card for storing configuration files and/
or software updates.
Configuration hazard hazard – risk of data loss.
The microSD card must not be removed or replaced during normal operation of the
device. Make sure the device is powered down before removing or inserting the
card.
Mechanical/electrical hazard – risk of damage to the microSD card
•
•
•
RUGGEDCOM RX1400
Installation Manual, 01/2021, C79000-G8976-1103-17
Remove the SIM card access panel.
1
Access Panel
1
Secondary Micro-SIM Card
2
Primary Micro-SIM Card
3
Figure 3.2
Accessing the SIM Cards
Insert the SIM cards into the slots. Slot 1 is for the primary SIM card and slot 2 is
for the secondary (backup) SIM card.
Close the access panel and secure it with the two screws.
Once the device is fully installed, activate the micro-SIM cards for the LTE
modem. For more information, refer to the RUGGEDCOM ROX-II Configuration
Manual for the RUGGEDCOM RX1400.
NOTICE
NOTICE
Do not expose the microSD card to extreme temperatures or humidity.
Do not expose the microSD card to large magnetic or static electric fields.
Do not bend or drop the microSD card.
3.4 Inserting/Removing the MicroSD Card
3
2
