Device Management
3.2 Configuring the Device
For information about how to connect to the device via the serial console port, refer
to the RUGGEDCOM ROX-II CLI Configuration Manual for the RUGGEDCOM RX1400.
Communication Ports
Connect any of the available Ethernet ports on the device to a management
switch and access the RUGGEDCOM RX1400 console and Web interfaces via the
device's IP address. The factory default IP address for the RUGGEDCOM RX1400 is
https://192.168.0.2.
For more information about available ports, refer to
33)".
Note
Single-mode fiber ports only support Ultra Physical Contact (UPC) cable connectors.
3.2

Configuring the Device

Once the device is installed and connected to the network, it must be configured.
All configuration management is done via the RUGGEDCOM RX1400 interface. For
more information about configuring the device, refer to the RUGGEDCOM ROX-II
Configuration Manual associated with the installed software release.
3.3

Installing the SIM Cards

The RUGGEDCOM RX1400 supports dual micro-SIM cards for the LTE modem to
provide a fail-over mechanism should one of the SIM cards lose connectivity with the
network.
To install micro-SIM cards from a regional cellular carrier, do the following:
Static electricity hazard – risk of damage to equipment
Take appropriate anti-static precautions before accessing the SIM cards.
30
Pin
8
9
NOTICE
Name
Reserved (Do Not Connect)
Reserved (Do Not Connect)
"Communication Ports (Page
Installation Manual, 01/2021, C79000-G8976-1103-17
RUGGEDCOM RX1400
