Introduction
1.4 Required Tools and Materials
D09
D10
D11
Ethernet Connection Options
E00
E01
L3 Software Options
F00
F01
LTE Antenna Options
G00
G01
G02
Virtual Processing Engine (VPE) Options
V00
V01
V02
V03
1.4

Required Tools and Materials

The following tools and materials are required to install the RUGGEDCOM RX1400:
WLAN, LTE and/or GPS antennas
Antenna N-connect and/or SMA cables
AC/DC power cord (16 AWG)
Lightning protector
Shielded coaxial cables
SIM card(s) provided by the network carrier
Flathead screwdriver for mounting the device to a DIN rail
Phillips screwdriver for mounting the device to a rack or panel
6
Option
SFP, SM, 10 km, 1490 nm TX, 1310 nm RX, 1000BX (-40C to +85C)
SFP, SM, 40 km, 1490 nm TX, 1310 nm RX, 1000BX (-40C to +85C)
SFP, SM, 2 km, 1310 nm, 100FX (-40C to +85C)
Option
Standard RJ45 Ports
Secure Collar for FastConnect Cables
Option
Layer 3 Standard Edition
Layer 3 Security Edition
Option
None
Single Direct Connect LTE Swivel Antenna
Two Direct Connect LTE Swivel Antennas
Option
VPE Disabled
VPE Enabled
RUGGEDCOM CloudConnect for VPE1400
RUGGEDCOM CROSSBOW ADM for VPE1400
Tool/Material
Description
Description
Description
Description
Description
Available For Purchase
From Siemens
Installation Manual, 01/2021, C79000-G8976-1103-17
a
ü
ü
û
û
û
û
û
û
RUGGEDCOM RX1400
