Gain
Average 3D gain
Isolation between GNSS and
LTE Main (Primary)
Typical VSWR
Polarization
a
Vertical linear polarization is sufficient.
b
Gv and Gh are measured and averaged over -45 to 90° in elevation, and ± 180° in azimuth.
5.6

WLAN Specifications

Supported Standards
Maximum Throughput
Diversity
Host Interface
Maximum EIRP
5.7

Operating Environment

The RUGGEDCOM RX1400 is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
Ambient Storage
Temperature
Ambient Relative
Humidity
Maximum Altitude
Maximum Altitude
a
Ambient Temperature as measured from a 30 cm radius surrounding the center of the enclosure.
b
Operating temperature may vary based on the limitations of installed SFPs. Refer to the RUGGEDCOM
SFP Transceivers Catalog for SFP temperature ratings.
c
Maximum ambient operating temperature is 70 °C (158 °F) when the device is installed along with
Underwriter Laboratories (UL) listed devices.
d
Non-condensing
RUGGEDCOM RX1400
Installation Manual, 01/2021, C79000-G8976-1103-17
•
•
> -5 dBi
> 10 dB in all uplink bands
< 2:5:1
Any other than LHCP (Left-Hand Circular Polarized) is acceptable.
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
TCP: 80 Mbps at 2.4 GHz
UDP: 100 Mbps at 2.4 GHz
2.4 GHz MRC support for extended range
5.0 GHz diversity capable
4-Bit SDIO
< 200 mW at 5250 to 5350 MHz
-40 to 85 °C (-40 to 185 °F)
ab
-40 to 85°C (-40 to 185 °F)
5% to 95%
d
2000 m (6562 ft)
2000 m (6562 ft)
Maximum gain and uniform coverage in the high elevation
angle and zenith
Gain in azimuth plane is not desired
c
Technical Specifications
5.6 WLAN Specifications
