Table 17: Cat 5e Cable Subnetwork Data Bus Physical Specifications and Cable Requirements
Parameter
Multi-drop
EOL terminations
Shield grounding
Distech Controls recommends the Cat 5e cables shown below. Cables fitted with connectors
are crimped as T568B.
Table 18: Distech Controls Recommended Cable Types to use for the Cat 5e Cable Subnetwork Data Bus
Cable Type
0.3m (1 ft.), Cat 5e Cable fit-
ted with RJ-45 Connectors
4.6m (15 ft.), Cat 5e Cable fit-
ted with RJ-45 Connectors
9m (30 ft.), Cat 5e Cable fit-
ted with RJ-45 Connectors
15m (50 ft.), Cat 5e Cable fit-
ted with RJ-45 Connectors
22m (75 ft.), Cat 5e Cable fit-
ted with RJ-45 Connectors
30m (100 ft.), Cat 5e Cable
fitted with RJ-45 Connectors
300 m (1000 feet), Cat 5e
Cable – Without Connectors
100 Crimp RJ-45 Connectors
1. Outer cable diameter – This does not take into account the RJ-45 connector.
Cat 5e Cable Subnetwork Bus Topology and End-of-Line Ter-
minations
The EOL termination settings for the Cat 5e Cable subnetwork data bus will vary depending
on the type of controller the room device or extension module is connected to. By default, all
80
Details
Daisy-chain (no T-connections)
Most room devices have two RJ-45 female pass-through
connectors to facilitate the daisy-chain connection of room
devices.
For the EC-Multi-Sensor: An optional ECx-Subnet Adapter
(Y-splitter) is available to facilitate the daisy-chain connec-
tion of room devices. The ECx-Subnet Adapter must be con-
nected directly to the EC-Multi-Sensor and its length cannot
be extended.
Must be set / enabled on the last room device only. This
does not apply to the ECx-Display.
Not applicable
Non-Plenum Applications
(Use in Conduit - FT4)
Part Number
O.D. (Ø)
CB-CAT5PC4WH0001 4.6mm (0.18in.)
CB-CAT5PC4WH0015 4.6mm (0.18in.)
CB-CAT5PC4WH0030 4.6mm (0.18in.)
CB-CAT5PC4WH0050 4.6mm (0.18in.)
CB-CAT5PC4WH0075 4.6mm (0.18in.)
CB-CAT5PC4WH0100 4.6mm (0.18in.)
CB-W244P-1446WHTB 4.6mm (0.18in.)
CB-W5506E N/A
Plenum Applications
(FT6)
1
Part Number
CB-CAT5PC6WH0001
CB-CAT5PC6WH0015
CB-CAT5PC6WH0030
CB-CAT5PC6WH0050
CB-CAT5PC6WH0075
CB-CAT5PC6WH0100
CB-W244P-2176WHTB
CB-W5506E
1
O.D. (Ø)
4.6mm (0.18in.)
4.6mm (0.18in.)
4.6mm (0.18in.)
4.6mm (0.18in.)
4.6mm (0.18in.)
4.6mm (0.18in.)
4.6mm (0.18in.)
N/A
Network Guide
