Error Display

The Error Display log can be accessed on the Operate screen while you are running the job or after you stop the
job. Click on an error to view the barcode image and barcode parameters.
Error Display Log
To hide the barcode parameters, click the "Hide Barcode Stats" button; this removes the barcode parameters from
the screen and enlarges the barcode image.
Note: After clicking the "Hide Barcode Stats" button, the name changes to "Show Barcode Stats."
Click this button to display the barcode parameters on the screen.
LVS-7000 Operations Manual Version 5.6.X
LVS-7000 Operations Manual Version 5.6.X
After clicking the "Hide
Barcode Stats" button, the
barcode parameters are
hidden and the barcode
image is enlarged.
Click the "Show Barcode
Stats" button to display the
barcode parameters on the
screen.
Barcode
parameters
