Direction Box
The box labeled Direction is applicable when using the OCR or OCV features; it tells the system the orientation in
which to read the characters across the screen. Five types of directions are available:
IMPORTANT: The LVS-7000 does not distinguish between touching/overlapping characters;
thus, characters must not touch or overlap. The LVS-7000 reads and/or verifies uppercase
characters only.
Direction
Left to right
Top to bottom
Right to left
Bottom to Top
Direction Examples
Left to Right:
Discard This Sector
If you have incorrectly drawn a sector, click the Discard this Sector button and then select the right arrow
button. The sector is deleted. Sectors can also be removed by hitting the delete key while a sector(s) is active.
LVS-7000 Operations Manual Version 5.6.X
Reads characters from left to right. Typically, this is the desired direction.
Reads characters from top to bottom.
Reads characters from right to left.
Reads characters from bottom to top.
Top to Bottom:
LVS-7000 Operations Manual Version 5.6.X
Description
Bottom to Top:
Right to Left:
