Pharmacode indicates whether pharmacode is included in the automatic 1D barcode
reading/discrimination:
Pharmacode=0 means pharmacode is not included in the automatic 1D barcode
o
reading/discrimination.
Pharmacode=1 indicates pharmacode is included in the automatic 1D barcode
o
reading/discrimination.

PhotoeyeSignalDelay is utilized to externally synchronize a line scan, or trigger an area scan LVS-7000.

RelearnAuthorization – When enabled, prevents the operator from using the "Ctrl+L" shortcut key or
"Update Spot Ignore" feature unless the operator has administrative rights. If the operator does not have
administrative rights, a pop-up message will appear requiring the operator to enter an authorized user
name and password.
RelearnAuthorization=0 indicates a pop-up message will not appear. Any user can press Ctrl+L
o
and any user with "Allow Accept/Replace Errors" privileges can press "Update Spot Ignore"
RelearnAuthorization=1 indicates a pop-up message will appear when an operator attempts to
o
use Ctrl+L or "Update Spot Ignore". The operator must enter an administrator user name and
password to continue.

ReportUnusedCodes - If enabled, a button entitled "Report unused codes" appears. This is used to
generate a report of codes that were in the match file, but never seen by the system.

ResyncMatchFileOnMismatch - If enabled, whenever a mismatch error occurs, the system will assume it
is possibly not in the right location in the match file and try to find where it is again. This allows the system
to recover instead of generating non-stop mismatch errors after an inserted or deleted label.

RollOutputFilePath is used in conjunction with the AutoBreakRoll feature. The path is where to store the
roll output files.

RollsPerCase is used in conjunction with LaneDivision=4. It is the number of rolls in a case. Once this
number is reached, the case number is incremented, and the roll number goes back to 1.

SerialNumber is the LVS-7000 serial number and should never be changed.

ShowAdditionalCounters=0
ShowAdditionalCounters=0 feature is off.
o
ShowAdditionalCounters=1 shows good and waste footage on the Operation screen.
o
 ShowBlemishMotion should only be changed by an Omron Microscan Technician.

ShowElapsedTime is not user configurable and should not be altered unless requested by a qualified
Omron Microscan representative.

ShowJobReportButton=0
ShowJobReportButton=0 feature is off.
o
ShowJobReportButton=1 prints a Job Summary report at time of job naming.
o

ShowReportLabel enables or disables the "Report label" field on the "Step 5: Setup Matching" screen.
The Report label field acts as a unique user-defined identifier of a sector.
ShowReportLabel=0 (default) – disables the "Report label" field on the "Step 5: Setup Matching"
o
screen.
ShowReportLabel=1 – enables the "Report label" field on the "Step 5: Setup Matching" screen.
o

ShowRuntimeGradeStats enables or disables the "Hide Barcode Stats" button on the Error Display
screen.
ShowRuntimeGradeStats=0 (default) – Disables the "Hide Barcode Stats" button.
o
ShowRuntimeGradeStats=1 – Enables the "Hide Barcode Stats" button.
o

ShowSnapshotButton=1 enables the "Snapshot" button to appear on the "Operate: Running the Job"
screen that enables a snapshot to be taken of the next repeat. This setting should not be altered unless
instructed by an Omron Microscan representative.
ShowSnapshotButton=0 disables the "Snapshot" button.
o

ShowStatusAlert enables the Bypass and MakeReady screens to flash colors (Bypass screen flashes
yellow/white; MakeReady screen flashes red/white), and enable the scrolling message ("Bypass" or
"MakeReady") to appear across the top, left corner of the screen.
ShowStatusAlert=0 disables the flashing screens and scrolling text.
o
ShowStatusAlert=1 enables the flashing screens and scrolling text.
o
