2. Fieldbus Connectivity

2.1. Overview

The following fieldbus networks are supported:
Fieldbus
For
Network
Compact 2
Modbus RTU
CAN
Ethernet/IP -
Modbus TCP -
Profibus DP
DeviceNet
www.invertekdrives.com
Requires Option
For Optidrive For Optidrive
E3 IP20 E3 IP66
Built In
Built In
- "-EIP"
- "-MTP"
OD-PROFB-IN
OD-DEVNET-IN
Supported
Communication Type
R/W Holding Registers
2 x PDO & SDO
6. Ethernet Connection and
Cyclic & Acyclic
8. Ethernet/IP Communication
R/W Holding Registers 6. Ethernet Connection
Cyclic Control Only 10. Fieldbus Gateways
Cyclic Control Only 10. Fieldbus Gateways
Version 1.00 | Fieldbus Guide | 5
Refer to Section
4. Modbus RTU
5. CAN
