Invertek Drives Optidrive E3 ODE-3 Series User Manual page 39

Modbus CAN
Sub
RTU Open
Index
Register Index
25 - -
26 - -
27 - -
28 - -
29 2017h 0
30 - -
31 - -
32 203Ch 0
33 203Dh 0
34 203Eh 0
35 203Fh 0
36 2040h 0
37 2041h 0
38 - -
39 2010h 0
40 2044h 0
41 - -
42 2046h 0
43 2048h 0
44 - -
45 - -
46 - -
- 2049h 0
- 23E8h 0
- 23E9h 0
- 27D0h 0
- 27D1h 0
- 27D2h 0
- 27D3h 0
- 27D4h 0
- 27D5h 0
- 27D6h 0
- 26D7h 0
- 27D8h 0
- 27D9h 0
- 27DAh 0
- 27DBh 0
- 27DCh 0
- 27DDh 0
www.invertekdrives.com
PDO Parameter
Upper byte Lower Byte Format
Map Number
P0-30 Drive Serial Number 4
P0-30 Drive Serial Number 3
P0-30 Drive Serial Number 2
P0-30 Drive Serial Number 1
Y - Relay Output Status
- Reserved
- Reserved
Y P0-26 kWh Meter
Y P0-26 MWh Meter
Y P0-10 Running Time – Hours
Y P0-10 Running Time – Minutes &
Seconds
Y P0-14 Run time since last enable –
Hours
Y P0-14 Run time since last enable –
Minutes & seconds
- Reserved
Y P0-20 Internal Drive Temperature
Y - Speed Reference (Internal
Format)
- Reserved
Y Digital Pot / Keypad Reference
Y P0-07 Output Voltage
- Parameter Access Index
- Parameter Access Value
N - Parameter Checksum
Y P0-05 PI Output
N - Scope Index 12
N - Scope Index 34
N P0-1 1 Run Time Since Last Trip 1 –
Hours
N P0-1 1 Run Time Since Last Trip 1 -
Seconds
N P0-12 Run Time Since Last Trip 2 –
Hours
N P0-12 Run Time Since Last Trip 2 -
Seconds
N P0-13 Trip Log 2 & 1
N P0-13 Trip Log 4 & 3
N P0-13 Trip 1 Time – Hours
N P0-13 Trip 1 Time - Seconds
N P0-13 Trip 2 Time – Hours
N P0-13 Trip 2 Time - Seconds
N P0-13 Trip 3 Time – Hours
N P0-13 Trip 3 Time - Seconds
N P0-13 Trip 4 Time – Hours
N P0-13 Trip 4 Time - Seconds
Type Scaling
U16 R See Below
U16 R
U16 R
U16 R
WORD R Bit 0 Indicates Relay Status
1 = Relay Contacts Closed
- R No Function
- R No Function
U16 R 1dp, e.g. 100 = 10.0kWh
U16 R 10 = 10MWh
U16 R 1 = 1 Hour
U16 R 100 = 100 Seconds
U16 R 1 = 1 Hour
U16 R 100 = 100 Seconds
U16 R No Function
S16 R 20 = 20C
U16 R 3000 = 50Hz
- R No Function
U16 R 3000 = 50Hz
U16 R 100 = 100 Volts AC RMS
U16 R See Below
S16 R See Below
U16 R See Below
U16 R 1000 = 100.0%
RW
RW
U16 R 1 = 1 Hour
U16 R 100 = 100 Seconds
U16 R 1 = 1 Hour
U16 R 100 = 100 Seconds
WORD R
WORD R
U16 R 1 = 1 Hour
U16 R 100 = 100 Seconds
U16 R 1 = 1 Hour
U16 R 100 = 100 Seconds
U16 R 1 = 1 Hour
U16 R 100 = 100 Seconds
U16 R 1 = 1 Hour
U16 R 100 = 100 Seconds
Version 1.00 | Fieldbus Guide | 39
