Module Status (MS) Indicator
State Indication
Steady Off No power
Steady Green Operating in normal condition
Flashing Green Drive not configured
Flashing Red Minor fault - Recoverable fault
Steady Red Major fault - Unrecoverable fault
Flashing Green / Red Self-test
COMM
State Indication
Steady Off Modbus protocol TX/RX inactive
Steady/flashing Yellow Modbus protocol TX/RX active
ERROR
State Indication
Steady Off Modbus protocol TX/RX Status OK
Steady Red Non-recoverable internal fault – Modbus communications circuit fault
Flashing Red Recoverable Communication fault or configuration error
Link Activity LEDs (P1/P2)
State State
P1 Speed Steady Yellow
Steady Off
P1 Link Activity Steady Green
Steady Off
Flash
P2 Speed Steady Yellow
Steady Off
P2 Link Activity Steady Green
Steady Off
Flash
www.invertekdrives.com
Indication
100Mbps link active
10Mbps or No link
Valid Link
No Link
TX/RX
100Mbps link active
10Mbps or No link
Valid Link
No Link
TX/RX
